Keysight Technologies InfiniiVision 4000 X Series User Manual

Commands Quick Reference 5
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 169
:SBUS<n>:CXPI:TOLeran
ce <percent> (see
page 912)
:SBUS<n>:CXPI:TOLeran
ce? (see page 912)
<percent> ::= from 1-30, in NR1
format.
:SBUS<n>:CXPI:TRIGger
<mode> (see page 913)
:SBUS<n>:CXPI:TRIGger
? (see page 914)
<mode> ::= {SOF | EOF | PTYPe |
ID | DATA | LDATa | CRCerror |
PARityerror | IBSerror | IFSerror
| FRAMingerror | DLENgtherror |
SAMPleerror | ALLerrors |
SLEepframe | WAKeuppulse}
:SBUS<n>:CXPI:TRIGger
:IDFilter {{0 | OFF}
| {1 | ON}} (see
page 915)
:SBUS<n>:CXPI:TRIGger
:IDFilter? (see
page 915)
{0 | 1}
:SBUS<n>:CXPI:TRIGger
:PTYPe {{0 | OFF} |
{1 | ON}} (see
page 916)
:SBUS<n>:CXPI:TRIGger
:PTYPe? (see page 916)
{0 | 1}
:SBUS<n>:CXPI:TRIGger
:PATTern:DATA
<string> (see
page 917)
:SBUS<n>:CXPI:TRIGger
:PATTern:DATA? (see
page 917)
<string> ::= "nn...n" where n ::=
{0 | 1 | X}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X}
:SBUS<n>:CXPI:TRIGger
:PATTern:DATA:LENGth
<length> (see
page 918)
:SBUS<n>:CXPI:TRIGger
:PATTern:DATA:LENGth?
(see page 918)
<start> ::= integer between 0 and
12, in NR1 format.
:SBUS<n>:CXPI:TRIGger
:PATTern:DATA:STARt
<start> (see page 919)
:SBUS<n>:CXPI:TRIGger
:PATTern:DATA:STARt?
(see page 919)
<start> ::= integer between 0 and
124, in NR1 format.
:SBUS<n>:CXPI:TRIGger
:PATTern:ID <string>
(see page 920)
:SBUS<n>:CXPI:TRIGger
:PATTern:ID? (see
page 920)
<string> ::= "nn...n" where n ::=
{0 | 1 | X}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X}
:SBUS<n>:CXPI:TRIGger
:PATTern:INFO:CT
<string> (see
page 921)
:SBUS<n>:CXPI:TRIGger
:PATTern:INFO:CT?
(see page 921)
<string> ::= "nn" where n ::= {0
| 1 | X}
Table 30 :SBUS<n>:CXPI Commands Summary (continued)
Command Query Options and Query Returns
