5 Commands Quick Reference
:SBUS<n>:CXPI:TRIGger
:PATTern:INFO:DLC
<dlc> (see page 922)
:SBUS<n>:CXPI:TRIGger
:PATTern:INFO:DLC?
(see page 922)
<dlc> ::= integer between -1
(don't care) and 15, in NR1
format, when trigger is in DATA
mode.
<dlc> ::= integer between -1
(don't care) and 255, in NR1
format, when trigger is in LDATa
mode.
:SBUS<n>:CXPI:TRIGger
:PATTern:INFO:NM
<string> (see
page 923)
:SBUS<n>:CXPI:TRIGger
:PATTern:INFO:NM?
(see page 923)
<string> ::= "nn" where n ::= {0
| 1 | X}
Table 30 :SBUS<n>:CXPI Commands Summary (continued)
Command Query Options and Query Returns
Table 31 :SBUS<n>:FLEXray Commands Summary
Command Query Options and Query Returns
:SBUS<n>:FLEXray:AUTo
setup (see page 926)
n/a n/a
:SBUS<n>:FLEXray:BAUD
rate <baudrate> (see
page 927)
:SBUS<n>:FLEXray:BAUD
rate? (see page 927)
<baudrate> ::= {2500000 | 5000000
| 10000000}
:SBUS<n>:FLEXray:CHAN
nel <channel> (see
page 928)
:SBUS<n>:FLEXray:CHAN
nel? (see page 928)
<channel> ::= {A | B}
n/a :SBUS<n>:FLEXray:COUN
t:NULL? (see page 929)
<frame_count> ::= integer in NR1
format
:SBUS<n>:FLEXray:COUN
t:RESet (see page 930)
n/a n/a
n/a :SBUS<n>:FLEXray:COUN
t:SYNC? (see page 931)
<frame_count> ::= integer in NR1
format
n/a :SBUS<n>:FLEXray:COUN
t:TOTal? (see
page 932)
<frame_count> ::= integer in NR1
format
:SBUS<n>:FLEXray:SOUR
ce <source> (see
page 933)
:SBUS<n>:FLEXray:SOUR
ce? (see page 933)
<source> ::= {CHANnel<n>}
<n> ::= 1-2 or 1-4 in NR1 format
:SBUS<n>:FLEXray:TRIG
ger <condition> (see
page 934)
:SBUS<n>:FLEXray:TRIG
ger? (see page 934)
<condition> ::= {FRAMe | ERRor |
EVENt}
