Commands Quick Reference 5
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 171
:SBUS<n>:FLEXray:TRIG
ger:ERRor:TYPE
<error_type> (see
page 935)
:SBUS<n>:FLEXray:TRIG
ger:ERRor:TYPE? (see
page 935)
<error_type> ::= {ALL | HCRC |
FCRC}
:SBUS<n>:FLEXray:TRIG
ger:EVENt:AUToset
(see page 936)
n/a n/a
:SBUS<n>:FLEXray:TRIG
ger:EVENt:BSS:ID
<frame_id> (see
page 937)
:SBUS<n>:FLEXray:TRIG
ger:EVENt:BSS:ID?
(see page 937)
<frame_id> ::= {ALL | <frame #>}
<frame #> ::= integer from 1-2047
:SBUS<n>:FLEXray:TRIG
ger:EVENt:TYPE
<event> (see page 938)
:SBUS<n>:FLEXray:TRIG
ger:EVENt:TYPE? (see
page 938)
<event> ::= {WAKeup | TSS | {FES
| DTS} | BSS}
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:CCBase
<cycle_count_base>
(see page 939)
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:CCBase?
(see page 939)
<cycle_count_base> ::= integer
from 0-63
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:CCRepetitio
n
<cycle_count_repetiti
on> (see page 940)
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:CCRepetitio
n? (see page 940)
<cycle_count_repetition> ::=
{ALL | <rep #>}
<rep #> ::= integer values 2, 4,
8, 16, 32, or 64
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:ID
<frame_id> (see
page 941)
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:ID? (see
page 941)
<frame_id> ::= {ALL | <frame #>}
<frame #> ::= integer from 1-2047
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:TYPE
<frame_type> (see
page 942)
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:TYPE? (see
page 942)
<frame_type> ::= {NORMal |
STARtup | NULL | SYNC | NSTArtup
| NNULl | NSYNc | ALL}
Table 31 :SBUS<n>:FLEXray Commands Summary (continued)
Command Query Options and Query Returns
Table 32 :SBUS<n>:I2S Commands Summary
Command Query Options and Query Returns
:SBUS<n>:I2S:ALIGnmen
t <setting> (see
page 946)
:SBUS<n>:I2S:ALIGnmen
t? (see page 946)
<setting> ::= {I2S | LJ | RJ}
:SBUS<n>:I2S:BASE
<base> (see page 947)
:SBUS<n>:I2S:BASE?
(see page 947)
<base> ::= {DECimal | HEX}
