20 :FUNCtion<m> Commands
Introduction to
:FUNCtion<m>
Commands
The FUNCtion subsystem controls the math functions in the oscilloscope. Four
math functions are available — the <m> in :FUNCtion<m> can be from 1 to 4.
The math function operator, transform, filter, or visualization is selected using the
:FUNCtion<m>:OPERation command. Depending on the selected operation, there
may be other commands for specifying options for that operation. See
":FUNCtion<m>:OPERation" on page 490.
The SOURce1, DISPlay, RANGe, and OFFSet (or REFerence) commands apply to
any function.
Reporting the Setup
Use :FUNCtion<m>? to query setup information for the FUNCtion subsystem.
Return Format
:FUNCtion<m>:SOURce1
<source> (see
page 498)
:FUNCtion<m>:SOURce1?
(see page 498)
<source> ::= {CHANnel<n> |
FUNCtion<c> | MATH<c> |
WMEMory<r> | BUS<b>}
<n> ::= 1 to (# analog channels)
in NR1 format
<c> ::= {1 | 2 | 3}, must be
lower than <m>
<r> ::= 1 to (# ref waveforms) in
NR1 format
<b> ::= {1 | 2}
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:SOURce2
<source> (see
page 500)
:FUNCtion<m>:SOURce2?
(see page 500)
<source> ::= {CHANnel<n> |
WMEMory<r> | NONE}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:TRENd:NM
Easurement MEAS<n>
(see page 501)
:FUNCtion<m>:TRENd:NM
Easurement? (see
page 501)
<n> ::= # of installed
measurement, from 1 to 10
<m> ::= 1 to (# math functions)
in NR1 format
Table 106 :FUNCtion<m> Commands Summary (continued)
Command Query Options and Query Returns
