31 :SBUS<n> Commands
:SBUS<n>:SPI:SOURce:M
ISO <source> (see
page 1082)
:SBUS<n>:SPI:SOURce:M
ISO? (see page 1082)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:SPI:SOURce:M
OSI <source> (see
page 1083)
:SBUS<n>:SPI:SOURce:M
OSI? (see page 1083)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:DATA
<string> (see
page 1084)
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:DATA?
(see page 1084)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:WIDTh
<width> (see
page 1085)
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:WIDTh?
(see page 1085)
<width> ::= integer from 4 to 64
in NR1 format
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:DATA
<string> (see
page 1086)
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:DATA?
(see page 1086)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:WIDTh
<width> (see
page 1087)
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:WIDTh?
(see page 1087)
<width> ::= integer from 4 to 64
in NR1 format
:SBUS<n>:SPI:TRIGger:
TYPE <value> (see
page 1088)
:SBUS<n>:SPI:TRIGger:
TYPE? (see page 1088)
<value> ::= {MOSI | MISO}
:SBUS<n>:SPI:WIDTh
<word_width> (see
page 1089)
:SBUS<n>:SPI:WIDTh?
(see page 1089)
<word_width> ::= integer 4-16 in
NR1 format
Table 129 :SBUS<n>:SPI Commands Summary (continued)
Command Query Options and Query Returns
