Keysight Technologies InfiniiVision 4000 X Series User Manual

Commands Quick Reference 5
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 113
:DISPlay:ANNotation<n
>:X1Position <value>
(see page 408)
:DISPlay:ANNotation<n
>:X1Position? (see
page 408)
<value> ::= an integer from 0 to
(800 - width of annotation) in
NR1 format.
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:Y1Position <value>
(see page 409)
:DISPlay:ANNotation<n
>:Y1Position? (see
page 409)
<value> ::= an integer from 0 to
(480 - height of annotation) in
NR1 format.
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:BACKlight
{{0 | OFF} | {1 |
ON}} (see page 410)
n/a n/a
:DISPlay:CLEar (see
page 411)
n/a n/a
n/a :DISPlay:DATA?
[<format>][,][<palett
e>] (see page 412)
<format> ::= {BMP | BMP8bit |
PNG}
<palette> ::= {COLor | GRAYscale}
<display data> ::= data in IEEE
488.2 # format
:DISPlay:GRATicule:AL
ABels {{0 | OFF} | {1
| ON}} (see page 414)
:DISPlay:GRATicule:AL
ABels? (see page 414)
<setting> ::= {0 | 1}
:DISPlay:GRATicule:IN
Tensity <value> (see
page 415)
:DISPlay:GRATicule:IN
Tensity? (see
page 415)
<value> ::= an integer from 0 to
100 in NR1 format.
:DISPlay:GRATicule:TY
PE <type> (see
page 416)
:DISPlay:GRATicule:TY
PE? (see page 416)
<type> ::= {FULL | MVOLt | IRE}
:DISPlay:INTensity:WA
Veform <value> (see
page 417)
:DISPlay:INTensity:WA
Veform? (see page 417)
<value> ::= an integer from 0 to
100 in NR1 format.
:DISPlay:LABel {{0 |
OFF} | {1 | ON}} (see
page 418)
:DISPlay:LABel? (see
page 418)
{0 | 1}
:DISPlay:LABList
<binary block> (see
page 419)
:DISPlay:LABList?
(see page 419)
<binary block> ::= an ordered
list of up to 75 labels, each 10
characters maximum, separated by
newline characters
Table 12 :DISPlay Commands Summary (continued)
Command Query Options and Query Returns
