5 Commands Quick Reference
:MEASure:BRATe
[<source>] (see
page 572)
:MEASure:BRATe?
[<source>] (see
page 572)
<source> ::= {<digital channels>
| CHANnel<n> | FUNCtion<m> |
MATH<m> | WMEMory<r>}
<digital channels> ::=
DIGital<d> for the MSO models
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<n> ::= 1 to (# of analog
channels) in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= bit rate in
Hz, NR3 format
:MEASure:BWIDth
[<source>] (see
page 573)
:MEASure:BWIDth?
[<source>] (see
page 573)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= burst width in
seconds, NR3 format
:MEASure:CLEar (see
page 574)
n/a n/a
:MEASure:COUNter
[<source>] (see
page 575)
:MEASure:COUNter?
[<source>] (see
page 575)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | EXTernal} for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= counter
frequency in Hertz in NR3 format
Table 20 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
