Commands Quick Reference 5
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 127
:MEASure:DEFine
DELay, <delay spec>
(see page 577)
:MEASure:DEFine?
DELay (see page 579)
<delay spec> ::=
<edge_spec1>,<edge_spec2>
edge_spec1 ::=
[<slope>]<occurrence>
edge_spec2 ::=
[<slope>]<occurrence>
<slope> ::= {+ | -}
<occurrence> ::= integer
:MEASure:DEFine
THResholds,
<threshold spec> (see
page 577)
:MEASure:DEFine?
THResholds (see
page 579)
<threshold spec> ::= {STANdard} |
{<threshold mode>,<upper>,
<middle>,<lower>}
<threshold mode> ::= {PERCent |
ABSolute}
:MEASure:DELay
[<source1>]
[,<source2>] (see
page 580)
:MEASure:DELay?
[<source1>]
[,<source2>] (see
page 580)
<source1,2> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r> | <digital channels>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<digital channels> ::=
DIGital<d> for the MSO models
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::=
floating-point number delay time
in seconds in NR3 format
:MEASure:DELay:DEFine
<source1_edge_slope>,
<source1_edge_number>
,
<source1_edge_thresho
ld>,
<source2_edge_slope>,
<source2_edge_number>
,
<source2_edge_thresho
ld> (see page 582)
:MEASure:DELay:DEFine
? (see page 582)
<source1_edge_slope>,
<source2_edge_slope> ::= {RISing
| FALLing}
<source1_edge_number>,
<source2_edge_number> ::= 0 to
1000 in NR1 format
<source1_edge_threshold>,
<source2_edge_threshold> ::=
MIDDle
Table 20 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
