Keysight Technologies InfiniiVision 4000 X Series

Commands Quick Reference 5
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 135
:MEASure:PHASe
[<source1>]
[,<source2>] (see
page 604)
:MEASure:PHASe?
[<source1>]
[,<source2>] (see
page 604)
<source1,2> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= the phase
angle value in degrees in NR3
format
:MEASure:PPULses
[<source>] (see
page 605)
:MEASure:PPULses?
[<source>] (see
page 605)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r> | <digital channels>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<digital channels> ::=
DIGital<d> for the MSO models
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= the rising
pulse count in NR3 format
:MEASure:PREShoot
[<source>] (see
page 606)
:MEASure:PREShoot?
[<source>] (see
page 606)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= the percent of
preshoot of the selected waveform
in NR3 format
Table 20 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
