36 :WAVeform Commands
:WAVeform:POINts
<# points> (see
page 1406)
:WAVeform:POINts?
(see page 1406)
<# points> ::= {100 | 250 | 500 |
1000 | <points_mode>} if waveform
points mode is NORMal
<# points> ::= {100 | 250 | 500 |
1000 | 2000 ... 8000000 in 1-2-5
sequence | <points_mode>} if
waveform points mode is MAXimum
or RAW
<points_mode> ::= {NORMal |
MAXimum | RAW}
:WAVeform:POINts:MODE
<points_mode> (see
page 1408)
:WAVeform:POINts:MODE
? (see page 1408)
<points_mode> ::= {NORMal |
MAXimum | RAW}
n/a :WAVeform:PREamble?
(see page 1410)
<preamble_block> ::= <format
NR1>, <type NR1>,<points
NR1>,<count NR1>, <xincrement
NR3>, <xorigin NR3>, <xreference
NR1>,<yincrement NR3>, <yorigin
NR3>, <yreference NR1>
<format> ::= an integer in NR1
format:
• 0 for BYTE format
• 1 for WORD format
• 2 for ASCii format
<type> ::= an integer in NR1
format:
• 0 for NORMal type
• 1 for PEAK detect type
• 3 for AVERage type
• 4 for HRESolution type
<count> ::= Average count, or 1
if PEAK detect type or NORMal; an
integer in NR1 format
:WAVeform:SEGMented:A
LL {{0 | OFF} | {1 |
ON}} (see page 1413)
:WAVeform:SEGMented:A
LL? (see page 1413)
<setting> ::= {0 | 1}
n/a :WAVeform:SEGMented:C
OUNt? (see page 1414)
<count> ::= an integer from 2 to
1000 in NR1 format
n/a :WAVeform:SEGMented:T
TAG? (see page 1415)
<time_tag> ::= in NR3 format
Table 166 :WAVeform Commands Summary (continued)
Command Query Options and Query Returns
