Keysight InfiniiVision 4000 X-Series Oscilloscopes
Programmer's Guide
37 :WGEN<w> Commands
When the built-in waveform generator is licensed (WAVEGEN license), you can
use it to output sine, square, ramp, pulse, DC, noise, sine cardinal, exponential
rise, exponential fall, cardiac, and gaussian pulse waveforms. The :WGEN<w>
commands are used to select the waveform function and parameters. See
"Introduction to :WGEN<w> Commands" on page 1435.
Table 167 :WGEN<w> Commands Summary
Command Query Options and Query Returns
:WGEN<w>:ARBitrary:BY
Teorder <order> (see
page 1436)
:WGEN<w>:ARBitrary:BY
Teorder? (see
page 1436)
<order> ::= {MSBFirst | LSBFirst}
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:ARBitrary:DA
TA {<binary> |
<value>, <value> ...}
(see page 1437)
n/a <binary> ::= floating point
values between -1.0 to +1.0 in
IEEE 488.2 binary block format
<value> ::= floating point values
between -1.0 to +1.0 in
comma-separated format
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
n/a :WGEN<w>:ARBitrary:DA
TA:ATTRibute:POINts?
(see page 1440)
<points> ::= number of points in
NR1 format
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:ARBitrary:DA
TA:CLEar (see
page 1441)
n/a <w> ::= 1 to (# WaveGen outputs)
in NR1 format
