Keysight Technologies InfiniiVision 4000 X Series

1432 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
37 :WGEN<w> Commands
:WGEN<w>:ARBitrary:DA
TA:DAC {<binary> |
<value>, <value> ...}
(see page 1442)
n/a <binary> ::= decimal 16-bit
integer values between -512 to
+511 in IEEE 488.2 binary block
format
<value> ::= decimal integer
values between -512 to +511 in
comma-separated NR1 format
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:ARBitrary:IN
Terpolate {{0 | OFF}
| {1 | ON}} (see
page 1443)
:WGEN<w>:ARBitrary:IN
Terpolate? (see
page 1443)
{0 | 1}
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:ARBitrary:ST
ORe <source> (see
page 1444)
n/a <source> ::= {CHANnel<n> |
WMEMory<r> | FUNCtion<m> |
MATH<m>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:FREQuency
<frequency> (see
page 1445)
:WGEN<w>:FREQuency?
(see page 1445)
<frequency> ::= frequency in Hz
in NR3 format
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:FUNCtion
<signal> (see
page 1446)
:WGEN<w>:FUNCtion?
(see page 1449)
<signal> ::= {SINusoid | SQUare |
RAMP | PULSe | NOISe | DC | SINC
| EXPRise | EXPFall | CARDiac |
GAUSsian | ARBitrary}
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:FUNCtion:PUL
Se:WIDTh <width> (see
page 1450)
:WGEN<w>:FUNCtion:PUL
Se:WIDTh? (see
page 1450)
<width> ::= pulse width in
seconds in NR3 format
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
Table 167 :WGEN<w> Commands Summary (continued)
Command Query Options and Query Returns
