Commands Quick Reference 5
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 173
:SBUS<n>:I2S:TRIGger:
PATTern:DATA <string>
(see page 956)
:SBUS<n>:I2S:TRIGger:
PATTern:DATA? (see
page 957)
<string> ::= "n" where n ::=
32-bit integer in signed decimal
when <base> = DECimal
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $} when <base> =
BINary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
when <base> = HEX
:SBUS<n>:I2S:TRIGger:
PATTern:FORMat <base>
(see page 958)
:SBUS<n>:I2S:TRIGger:
PATTern:FORMat? (see
page 958)
<base> ::= {BINary | HEX |
DECimal}
:SBUS<n>:I2S:TRIGger:
RANGe <lower>,<upper>
(see page 959)
:SBUS<n>:I2S:TRIGger:
RANGe? (see page 959)
<lower> ::= 32-bit integer in
signed decimal, <nondecimal>, or
<string>
<upper> ::= 32-bit integer in
signed decimal, <nondecimal>, or
<string>
<nondecimal> ::= #Hnn...n where n
::= {0,..,9 | A,..,F} for
hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F} for
hexadecimal
:SBUS<n>:I2S:TWIDth
<word_size> (see
page 960)
:SBUS<n>:I2S:TWIDth?
(see page 960)
<word_size> ::= 4-32 in NR1
format
:SBUS<n>:I2S:WSLow
<low_def> (see
page 961)
:SBUS<n>:I2S:WSLow?
(see page 961)
<low_def> ::= {LEFT | RIGHt}
Table 32 :SBUS<n>:I2S Commands Summary (continued)
Command Query Options and Query Returns
