Keysight Technologies InfiniiVision 4000 X Series

176 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
5 Commands Quick Reference
:SBUS<n>:LIN:TRIGger:
PATTern:DATA <string>
(see page 985)
:SBUS<n>:LIN:TRIGger:
PATTern:DATA? (see
page 985)
<string> ::= "n" where n ::=
32-bit integer in unsigned
decimal when <base> = DECimal
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $} when <base> =
BINary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
when <base> = HEX
:SBUS<n>:LIN:TRIGger:
PATTern:DATA:LENGth
<length> (see
page 987)
:SBUS<n>:LIN:TRIGger:
PATTern:DATA:LENGth?
(see page 987)
<length> ::= integer from 1 to 8
in NR1 format
:SBUS<n>:LIN:TRIGger:
PATTern:FORMat <base>
(see page 988)
:SBUS<n>:LIN:TRIGger:
PATTern:FORMat? (see
page 988)
<base> ::= {BINary | HEX |
DECimal}
:SBUS<n>:LIN:TRIGger:
SYMBolic:FRAMe <name>
(see page 989)
:SBUS<n>:LIN:TRIGger:
SYMBolic:FRAMe? (see
page 989)
<name> ::= quoted ASCII string
:SBUS<n>:LIN:TRIGger:
SYMBolic:SIGNal
<name> (see page 990)
:SBUS<n>:LIN:TRIGger:
SYMBolic:SIGNal? (see
page 990)
<name> ::= quoted ASCII string
:SBUS<n>:LIN:TRIGger:
SYMBolic:VALue <data>
(see page 991)
:SBUS<n>:LIN:TRIGger:
SYMBolic:VALue? (see
page 991)
<data> ::= value in NR3 format
Table 34 :SBUS<n>:LIN Commands Summary (continued)
Command Query Options and Query Returns
Table 35 :SBUS<n>:M1553 Commands Summary
Command Query Options and Query Returns
:SBUS<n>:M1553:AUTose
tup (see page 993)
n/a n/a
:SBUS<n>:M1553:BASE
<base> (see page 994)
:SBUS<n>:M1553:BASE?
(see page 994)
<base> ::= {BINary | HEX}
:SBUS<n>:M1553:SOURce
<source> (see
page 995)
:SBUS<n>:M1553:SOURce
? (see page 995)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:M1553:TRIGge
r:PATTern:DATA
<string> (see
page 996)
:SBUS<n>:M1553:TRIGge
r:PATTern:DATA? (see
page 996)
<string> ::= "nn...n" where n ::=
{0 | 1 | X}
