186 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
5 Commands Quick Reference
:SBUS<n>:UART:TRIGger
:QUALifier <value>
(see page 1109)
:SBUS<n>:UART:TRIGger
:QUALifier? (see
page 1109)
<value> ::= {EQUal | NOTequal |
GREaterthan | LESSthan}
:SBUS<n>:UART:TRIGger
:TYPE <value> (see
page 1110)
:SBUS<n>:UART:TRIGger
:TYPE? (see page 1110)
<value> ::= {RSTArt | RSTOp |
RDATa | RD1 | RD0 | RDX |
PARityerror | TSTArt | TSTOp |
TDATa | TD1 | TD0 | TDX}
:SBUS<n>:UART:WIDTh
<width> (see
page 1111)
:SBUS<n>:UART:WIDTh?
(see page 1111)
<width> ::= {5 | 6 | 7 | 8 | 9}
Table 40 :SBUS<n>:UART Commands Summary (continued)
Command Query Options and Query Returns
Table 41 :SBUS<n>:USB Commands Summary
Command Query Options and Query Returns
:SBUS<n>:USB:BASE
<base> (see page 1115)
:SBUS<n>:USB:BASE?
(see page 1115)
<base> ::= {ASCii | BINary |
DECimal | HEX}
:SBUS<n>:USB:SOURce:D
MINus <source> (see
page 1116)
:SBUS<n>:USB:SOURce:D
MINus? (see page 1116)
<source> ::= {CHANnel<n>} for DSO
models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:USB:SOURce:D
PLus <source> (see
page 1117)
:SBUS<n>:USB:SOURce:D
PLus? (see page 1117)
<source> ::= {CHANnel<n>} for DSO
models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:USB:SOURce:D
IFFerential <source>
(see page 1118)
:SBUS<n>:USB:SOURce:D
IFFerential? (see
page 1118)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:USB:SPEed
<speed> (see
page 1119)
:SBUS<n>:USB:SPEed?
(see page 1119)
<speed> ::= {LOW | FULL | HIGH}
