188 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
5 Commands Quick Reference
:SBUS<n>:USB:TRIGger:
PCHeck <string> (see
page 1129)
:SBUS<n>:USB:TRIGger:
PCHeck? (see
page 1129)
<string> ::= "nnnn" where n ::=
{0 | 1 | X}
<string> ::= "0xn" where n ::=
{0,..,9 | A,..,F | X | $}
:SBUS<n>:USB:TRIGger:
PID:DATA <pid> (see
page 1130)
:SBUS<n>:USB:TRIGger:
PID:DATA? (see
page 1130)
<pid> ::= {DATA0 | DATA1 | DATA2
| MDATa}
:SBUS<n>:USB:TRIGger:
PID:HANDshake <pid>
(see page 1131)
:SBUS<n>:USB:TRIGger:
PID:HANDshake? (see
page 1131)
<pid> ::= {ACK | NAK | STALl |
NYET}
:SBUS<n>:USB:TRIGger:
PID:SPECial <pid>
(see page 1132)
:SBUS<n>:USB:TRIGger:
PID:SPECial? (see
page 1132)
<pid> ::= {PING | PRE | ERR |
SPLit}
:SBUS<n>:USB:TRIGger:
PID:TOKen <pid> (see
page 1133)
:SBUS<n>:USB:TRIGger:
PID:TOKen? (see
page 1133)
<pid> ::= {OUT | IN | SETup |
SOF}
:SBUS<n>:USB:TRIGger:
PORT <string> (see
page 1134)
:SBUS<n>:USB:TRIGger:
PORT? (see page 1134)
<string> ::= "nnnnnnn" where n
::= {0 | 1 | X}
<string> ::= "0xnn" where n ::=
{0,..,9 | A,..,F | X | $}
:SBUS<n>:USB:TRIGger:
SC <string> (see
page 1135)
:SBUS<n>:USB:TRIGger:
SC? (see page 1135)
<string> ::= "n" where n ::= {0 |
1 | X}
<string> ::= "0xn" where n ::= {0
| 1 | X | $}
:SBUS<n>:USB:TRIGger:
SEU <string> (see
page 1136)
:SBUS<n>:USB:TRIGger:
SEU? (see page 1136)
<string> ::= "nn" where n ::= {0
| 1 | X}
<string> ::= "0xn" where n ::= {0
| 1 | 2 | 3 | X | $}
Table 41 :SBUS<n>:USB Commands Summary (continued)
Command Query Options and Query Returns
Table 42 :SBUS<n>:USBPd Commands Summary
Command Query Options and Query Returns
:SBUS<n>:USBPd:SOURce
<source> (see
page 1138)
:SBUS<n>:USBPd:SOURce
? (see page 1138)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:USBPd:TRIGge
r <mode> (see
page 1139)
:SBUS<n>:USBPd:TRIGge
r? (see page 1139)
<mode> ::= {PSTart | EOP | SOP |
SPRime | SDPRime | SPDebug |
SDPDebug | HRST | CRST | CRCerror
| PERRor | HEADer}
