Keysight Technologies InfiniiVision 4000 X Series

196 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
5 Commands Quick Reference
:SEARch:SERial:LIN:PA
TTern:DATA <string>
(see page 1218)
:SEARch:SERial:LIN:PA
TTern:DATA? (see
page 1218)
When
:SEARch:SERial:LIN:PATTern:FORMa
t DECimal, <string> ::= "n" where
n ::= 32-bit integer in unsigned
decimal, returns "$" if data has
any don't cares
When
:SEARch:SERial:LIN:PATTern:FORMa
t HEX, <string> ::= "0xnn...n"
where n ::= {0,..,9 | A,..,F | X
}
:SEARch:SERial:LIN:PA
TTern:DATA:LENGth
<length> (see
page 1219)
:SEARch:SERial:LIN:PA
TTern:DATA:LENGth?
(see page 1219)
<length> ::= integer from 1 to 8
in NR1 format
:SEARch:SERial:LIN:PA
TTern:FORMat <base>
(see page 1220)
:SEARch:SERial:LIN:PA
TTern:FORMat? (see
page 1220)
<base> ::= {HEX | DECimal}
:SEARch:SERial:LIN:SY
MBolic:FRAMe <name>
(see page 1221)
:SEARch:SERial:LIN:SY
MBolic:FRAMe? (see
page 1221)
<name> ::= quoted ASCII string
:SEARch:SERial:LIN:SY
MBolic:SIGNal <name>
(see page 1222)
:SEARch:SERial:LIN:SY
MBolic:SIGNal? (see
page 1222)
<name> ::= quoted ASCII string
:SEARch:SERial:LIN:SY
MBolic:VALue <data>
(see page 1223)
:SEARch:SERial:LIN:SY
MBolic:VALue? (see
page 1223)
<data> ::= value in NR3 format
Table 54 :SEARch:SERial:LIN Commands Summary (continued)
Command Query Options and Query Returns
Table 55 :SEARch:SERial:M1553 Commands Summary
Command Query Options and Query Returns
:SEARch:SERial:M1553:
MODE <value> (see
page 1225)
:SEARch:SERial:M1553:
MODE? (see page 1225)
<value> ::= {DSTArt | CSTArt |
RTA | RTA11 | PERRor | SERRor |
MERRor}
