5 Commands Quick Reference
:SEARch:SERial:SPI:PA
TTern:DATA <string>
(see page 1235)
:SEARch:SERial:SPI:PA
TTern:DATA? (see
page 1235)
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X}
:SEARch:SERial:SPI:PA
TTern:WIDTh <width>
(see page 1236)
:SEARch:SERial:SPI:PA
TTern:WIDTh? (see
page 1236)
<width> ::= integer from 1 to 10
Table 57 :SEARch:SERial:SPI Commands Summary (continued)
Command Query Options and Query Returns
Table 58 :SEARch:SERial:UART Commands Summary
Command Query Options and Query Returns
:SEARch:SERial:UART:D
ATA <value> (see
page 1238)
:SEARch:SERial:UART:D
ATA? (see page 1238)
<value> ::= 8-bit integer from
0-255 (0x00-0xff) in decimal,
<hexadecimal>, <binary>, or
<quoted_string> format
<hexadecimal> ::= #Hnn where n
::= {0,..,9| A,..,F} for
hexadecimal
<binary> ::= #Bnn...n where n ::=
{0 | 1} for binary
<quoted_string> ::= any of the
128 valid 7-bit ASCII characters
(or standard abbreviations)
:SEARch:SERial:UART:M
ODE <value> (see
page 1239)
:SEARch:SERial:UART:M
ODE? (see page 1239)
<value> ::= {RDATa | RD1 | RD0 |
RDX | TDATa | TD1 | TD0 | TDX |
PARityerror | AERRor}
:SEARch:SERial:UART:Q
UALifier <value> (see
page 1240)
:SEARch:SERial:UART:Q
UALifier? (see
page 1240)
<value> ::= {EQUal | NOTequal |
GREaterthan | LESSthan}
Table 59 :SEARch:SERial:USB Commands Summary
Command Query Options and Query Returns
:SEARch:SERial:USB:MO
DE <condition> (see
page 1243)
:SEARch:SERial:USB:MO
DE? (see page 1243)
<event> ::= {TOKen | DATA |
HANDshake | SPECial | ALLerrors |
PIDerror | CRC5error | CRC16error
| GLITcherror | STUFFerror |
SE1error}
:SEARch:SERial:USB:AD
DRess <string> (see
page 1244)
:SEARch:SERial:USB:AD
DRess? (see page 1244)
<string> ::= "0xnn" where n ::=
{0,..,9 | A,..,F | X | $}
