:WGEN<w>:MODulation:A
M:FREQuency
<frequency> (see
page 1454)
:WGEN<w>:MODulation:A
M:FREQuency? (see
page 1454)
<frequency> ::= modulating
waveform frequency in Hz in NR3
format
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:F
M:DEViation
<frequency> (see
page 1455)
:WGEN<w>:MODulation:F
M:DEViation? (see
page 1455)
<frequency> ::= frequency
deviation in Hz in NR3 format
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:F
M:FREQuency
<frequency> (see
page 1456)
:WGEN<w>:MODulation:F
M:FREQuency? (see
page 1456)
<frequency> ::= modulating
waveform frequency in Hz in NR3
format
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:F
SKey:FREQuency
<percent> (see
page 1457)
:WGEN<w>:MODulation:F
SKey:FREQuency? (see
page 1457)
<frequency> ::= hop frequency in
Hz in NR3 format
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:F
SKey:RATE <rate> (see
page 1458)
:WGEN<w>:MODulation:F
SKey:RATE? (see
page 1458)
<rate> ::= FSK modulation rate in
Hz in NR3 format
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:F
UNCtion <shape> (see
page 1459)
:WGEN<w>:MODulation:F
UNCtion? (see
page 1459)
<shape> ::= {SINusoid | SQUare|
RAMP}
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:F
UNCtion:RAMP:SYMMetry
<percent> (see
page 1460)
:WGEN<w>:MODulation:F
UNCtion:RAMP:SYMMetry
? (see page 1460)
<percent> ::= symmetry
percentage from 0% to 100% in NR1
format
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:N
OISe <percent> (see
page 1461)
:WGEN<w>:MODulation:N
OISe? (see page 1461)
<percent> ::= 0 to 100
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:S
TATe {{0 | OFF} | {1
| ON}} (see page 1462)
:WGEN<w>:MODulation:S
TATe? (see page 1462)
{0 | 1}
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:T
YPE <type> (see
page 1463)
:WGEN<w>:MODulation:T
YPE? (see page 1463)
<type> ::= {AM | FM | FSK}
<w> ::= 1 in NR1 format
:WGEN<w>:OUTPut {{0 |
OFF} | {1 | ON}} (see
page 1465)
:WGEN<w>:OUTPut? (see
page 1465)
{0 | 1}
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
Table 76 :WGEN<w> Commands Summary (continued)
Command Query Options and Query Returns
