Keysight Technologies InfiniiVision 4000 X Series

Commands Quick Reference 5
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 221
:WGEN<w>:VOLTage:HIGH
<high> (see page 1478)
:WGEN<w>:VOLTage:HIGH
? (see page 1478)
<high> ::= high-level voltage in
volts, in NR3 format
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:VOLTage:LOW
<low> (see page 1479)
:WGEN<w>:VOLTage:LOW?
(see page 1479)
<low> ::= low-level voltage in
volts, in NR3 format
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:VOLTage:OFFS
et <offset> (see
page 1480)
:WGEN<w>:VOLTage:OFFS
et? (see page 1480)
<offset> ::= offset in volts in
NR3 format
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
Table 76 :WGEN<w> Commands Summary (continued)
Command Query Options and Query Returns
Table 77 :WMEMory<r> Commands Summary
Command Query Options and Query Returns
:WMEMory<r>:CLEar
(see page 1483)
n/a <r> ::= 1 to (# ref waveforms) in
NR1 format
:WMEMory<r>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 1484)
:WMEMory<r>:DISPlay?
(see page 1484)
<r> ::= 1 to (# ref waveforms) in
NR1 format
{0 | 1}
:WMEMory<r>:LABel
<string> (see
page 1485)
:WMEMory<r>:LABel?
(see page 1485)
<r> ::= 1 to (# ref waveforms) in
NR1 format
<string> ::= any series of 10 or
less ASCII characters enclosed in
quotation marks
:WMEMory<r>:SAVE
<source> (see
page 1486)
n/a <r> ::= 1 to (# ref waveforms) in
NR1 format
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
NOTE: Math functions whose x-axis
is not frequency can be saved as
reference waveforms.
