300 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
8 :ACQuire Commands
Introduction to
:ACQuire
Commands
The ACQuire subsystem controls the way in which waveforms are acquired. These
acquisition types are available: normal, averaging, peak detect, and high
resolution.
Normal
The :ACQuire:TYPE NORMal command sets the oscilloscope in the normal
acquisition mode. For the majority of user models and signals, NORMal mode
yields the best oscilloscope picture of the waveform.
Averaging
The :ACQuire:TYPE AVERage command sets the oscilloscope in the averaging
mode. You can set the count by sending the :ACQuire:COUNt command followed
by the number of averages. In this mode, the value for averages is an integer from
2 to 65536. The COUNt value determines the number of averages that must be
acquired.
High-Resolution
The :ACQuire:TYPE HRESolution command sets the oscilloscope in the
high-resolution mode (also known as smoothing). This mode is used to reduce
noise at slower sweep speeds where the digitizer samples faster than needed to fill
memory for the displayed time range. Instead of decimating samples, they are
:ACQuire:SEGMented:AN
ALyze (see page 311)
n/a n/a
:ACQuire:SEGMented:CO
UNt <count> (see
page 312)
:ACQuire:SEGMented:CO
UNt? (see page 312)
<count> ::= an integer from 2 to
1000 in NR1 format
:ACQuire:SEGMented:IN
Dex <index> (see
page 313)
:ACQuire:SEGMented:IN
Dex? (see page 313)
<index> ::= an integer from 1 to
1000 in NR1 format
:ACQuire:SRATe[:ANALo
g] <rate> (see
page 316)
:ACQuire:SRATe[:ANALo
g]? (see page 316)
<rate> ::= {AUTO | <sample_rate>}
<sample_rate> ::= desired analog
sample rate in NR3 format
:ACQuire:SRATe[:ANALo
g]:AUTO {{0 | OFF} |
{1 | ON}} (see
page 317)
:ACQuire:SRATe[:ANALo
g]:AUTO? (see
page 317)
{0 | 1}
:ACQuire:TYPE <type>
(see page 318)
:ACQuire:TYPE? (see
page 318)
<type> ::= {NORMal | AVERage |
HRESolution | PEAK}
Table 94 :ACQuire Commands Summary (continued)
Command Query Options and Query Returns
