Keysight Technologies InfiniiVision 4000 X Series User Manual

:DEMO Commands 14
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 387
BURSt Burst of digital pulses that occur
every 50 µs @ ~ 3.6 Vpp, ~1.5 V
offset
Off
MSO 3.1 kHz stair-step sine wave output of
DAC @ ~1.5 Vpp, 0.75 V offset
DAC input signals are internally routed
to digital channels D0 through D7
~3.1 kHz sine wave filtered from DAC
output @ ~ 600 mVpp, 300 mV offset
RUNT Digital pulse train with positive and
negative runt pulses @ ~ 2.9 Vpp,
1.5 V offset
Off
TRANsition Digital pulse train with two different
edge speeds @ ~ 3.5 Vpp, 1.75 V
offset
Off
RFBurst 5-cycle burst of a 10 MHz amplitude
modulated sine wave @ ~ 2.6 Vpp,
0 V offset occurring once every 4 ms
Off
SHOLd 6.25 MHz digital clock @ ~ 3.5 Vpp,
1.75 V offset
Data signal @ ~3.5 Vpp, 1.75 V offset
LFSine 30 Hz sine wave @ ~2.7 Vpp, 0 V
offset, with very narrow glitch near
each positive peak
Off
FMBurst FM burst, modulated from ~100 kHz
to ~1 MHz, ~5.0 Vpp, ~600 mV offset.
Off
ETE 100 kHz pulse, 400 ns wide @
~3.3 Vpp, 1.65 V offset
600 ns analog burst (@ ~3.3 Vpp,
0.7 V offset) followed by 3.6 μs digital
burst @ ~3.3 Vpp, 1.65 V offset) at a
100 kHz repetitive rate
NFC ~2.4 Vpp unmodulated carrier
amplitude, ~1.8 Vpp maximum
modulated amplitude, ~0.0 V offset
Off
CAN CAN_L, 125 kbps dominant-low,
~2.8 Vpp, ~1.4 V offset
Off
LIN LIN, 19.2 kbs, ~2.8 Vpp, ~1.4 V offset Off
UART Receive data (RX) with odd parity,
19.2 kbps, 8-bit words, LSB out 1st,
low idle @ ~2.8 Vpp, 1.4 V offset
Transmit data (TX) with odd parity,
19.2 kbps, 8-bit words, LSB out 1st,
low idle @ ~ 2.8 Vpp, 1.4 V offset
I2C I2C serial clock signal (SCL) @
~2.8 Vpp, 1.4 V offset
I2C serial data signal (SDA) @ ~
2.8 Vpp, 1.4 V offset
Demo Signal
Function
Demo 1 Terminal Demo 2 Terminal
