Keysight Technologies InfiniiVision 4000 X Series

456 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
20 :FUNCtion<m> Commands
:FUNCtion<m>:BUS:YUNi
ts <units> (see
page 467)
:FUNCtion<m>:BUS:YUNi
ts? (see page 467)
<units> ::= {VOLT | AMPere |
NONE}
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:CLEar
(see page 468)
n/a n/a
:FUNCtion<m>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 469)
:FUNCtion<m>:DISPlay?
(see page 469)
{0 | 1}
<m> ::= 1 to (# math functions)
in NR1 format
n/a :FUNCtion<m>[:FFT]:BS
IZe? (see page 470)
<bin_size> ::= Hz in NR3 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>[:FFT]:CE
NTer <frequency> (see
page 471)
:FUNCtion<m>[:FFT]:CE
NTer? (see page 471)
<frequency> ::= the current
center frequency in NR3 format.
The range of legal values is from
-25 GHz to 25 GHz.
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>[:FFT]:DE
Tection:POINts
<number_of_buckets>
(see page 472)
:FUNCtion<m>[:FFT]:DE
Tection:POINts? (see
page 472)
<number_of_buckets> ::= an
integer from 640 to 64K in NR1
format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>[:FFT]:DE
Tection:TYPE <type>
(see page 473)
:FUNCtion<m>[:FFT]:DE
Tection:TYPE? (see
page 473)
<type> ::= {OFF | SAMPle |
PPOSitive | PNEGative | NORMal |
AVERage}
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>[:FFT]:FR
EQuency:STARt
<frequency> (see
page 474)
:FUNCtion<m>[:FFT]:FR
EQuency:STARt? (see
page 474)
<frequency> ::= the start
frequency in NR3 format.
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>[:FFT]:FR
EQuency:STOP
<frequency> (see
page 475)
:FUNCtion<m>[:FFT]:FR
EQuency:STOP? (see
page 475)
<frequency> ::= the stop
frequency in NR3 format.
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>[:FFT]:GA
TE <gating> (see
page 476)
:FUNCtion<m>[:FFT]:GA
TE? (see page 476)
<gating> ::= {NONE | ZOOM}
<m> ::= 1-4 in NR1 format
Table 106 :FUNCtion<m> Commands Summary (continued)
Command Query Options and Query Returns
