66 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
1 What's New
Changed
Commands
Command Differences From InfiniiVision 3000 X-Series Oscilloscopes
:ACQuire:MODE (see
page 307)
The ETIMe mode is available with the 1 GHz or 1.5 GHz
bandwidth models.
:CALibrate:OUTPut (see
page 335)
The TRIG OUT signal can be a trigger output, mask test failure, or
waveform generator sync pulse from either WaveGen1 or
WaveGen2.
:DEMO:FUNCtion (see
page 386)
The USB and NMONotonic functions are now available with the
educator's kit.
:DISPlay:VECTors (see
page 425)
The OFF parameter is available with the 1 GHz or 1.5 GHz
bandwidth models.
:FUNCtion<m>:OPERation (see
page 490)
The AVERage parameter is available for the Averaged Value math
function.
:MARKer:MODE (see
page 531)
You can now select the BINary or HEX marker modes.
:MEASure:SHOW (see
page 613)
This now has an OFF state when markers are not in measurement
mode.
:MEASure:WINDow (see
page 637)
This now has a GATE option for gated measurements between the
X1 and X2 cursors.
:RECall:ARBitrary:[STARt] (see
page 812)
There is now an option to specify which waveform generator to
recall the arbitrary waveform into.
:SAVE:ARBitrary:[STARt] (see
page 825)
There is now an option to specify which waveform generator to
save the arbitrary waveform from.
:SAVE:WAVeform:FORMat (see
page 846)
The ALB Keysight module binary format is not supported by the
4000 X-Series oscilloscopes.
:SBUS<n>:MODE (see
page 857)
The USB mode is now available with the USB 2.0 Full/Low Speed
or USB 2.0 High Speed serial decode and triggering licenses.
:TRIGger[:EDGE]:SOURce (see
page 1329)
You can now trigger on the WGEN1 or WGEN2 outputs or, when
FM or FSK modulation is used, you can trigger on the WMOD
modulating signal output.
:TRIGger:MODE (see
page 1308)
The USB mode has been superseded by commands that are
available with the USB 2.0 Full/Low Speed or USB 2.0 High Speed
serial decode and triggering licenses. See ":SBUS<n>:USB
Commands" on page 1112.
:WGEN<w> Commands (see
page 1431)
With the built-in waveform generator's (with Option WGN license)
two outputs, you can use :WGEN1 and :WGEN2 to specify which
output you are controlling. :WGEN is the same as :WGEN1.
Maximum waveform generator amplitudes and offsets are also
different.
:WMEMory<r> Commands (see
page 1481)
<r> is now from 1 to 4 with four reference waveform memories.
