3 Getting Started

When you send the :DIGitize command to the oscilloscope, the specified channel

signal is digitized with the current :ACQuire parameters. To obtain waveform data,

you must specify the :WAVeform parameters for the SOURce channel, the FORMat

type, and the number of POINts prior to sending the :WAVeform:DATA? query.

The number of data points comprising a waveform varies according to the number

requested in the :ACQuire subsystem. The :ACQuire subsystem determines the

number of data points, type of acquisition, and number of averages used by the

:DIGitize command. This allows you to specify exactly what the digitized

information contains.

The following program example shows a typical setup:

myScope.WriteString ":ACQuire:TYPE AVERage"

myScope.WriteString ":ACQuire:COMPlete 100"

myScope.WriteString ":ACQuire:COUNt 8"

myScope.WriteString ":DIGitize CHANnel1"

myScope.WriteString ":WAVeform:SOURce CHANnel1"

myScope.WriteString ":WAVeform:FORMat BYTE"

myScope.WriteString ":WAVeform:POINts 500"

myScope.WriteString ":WAVeform:DATA?"

This setup places the instrument into the averaged mode with eight averages. This

means that when the :DIGitize command is received, the command will execute

until the signal has been averaged at least eight times.

After receiving the :WAVeform:DATA? query, the instrument will start passing the

waveform information.

Digitized waveforms are passed from the instrument to the controller by sending a

numerical representation of each digitized point. The format of the numerical

representation is controlled with the :WAVeform:FORMat command and may be

selected as BYTE, WORD, or ASCii.

NOTE

Ensure New Data is Collected

When you change the oscilloscope configuration, the waveform buffers are cleared. Before

doing a measurement, send the :DIGitize command to the oscilloscope to ensure new data has

been collected.

NOTE

Set :TIMebase:MODE to MAIN when using :DIGitize

:TIMebase:MODE must be set to MAIN to perform a :DIGitize command or to perform any

:WAVeform subsystem query. A "Settings conflict" error message will be returned if these

commands are executed when MODE is set to ROLL, XY, or WINDow (zoomed). Sending the

*RST (reset) command will also set the time base mode to normal.
