178 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
5 Commands Quick Reference
:SBUS<n>:MANChester:S
OURce <source> (see
page 1009)
:SBUS<n>:MANChester:S
OURce? (see page 1009)
<source> ::= {CHANnel<n> |
DIGital<d>}
:SBUS<n>:MANChester:S
SIZe <#bits> (see
page 1010)
:SBUS<n>:MANChester:S
SIZe? (see page 1010)
<#bits> ::= from 0-255, in NR1
format
:SBUS<n>:MANChester:S
TARt <edge#> (see
page 1011)
:SBUS<n>:MANChester:S
TARt? (see page 1011)
<edge#> ::= from 1-256, in NR1
format
:SBUS<n>:MANChester:T
OLerance <percent>
(see page 1012)
:SBUS<n>:MANChester:T
OLerance? (see
page 1012)
<percent> ::= from 1-30, in NR1
format
:SBUS<n>:MANChester:T
RIGger <mode> (see
page 1013)
:SBUS<n>:MANChester:T
RIGger? (see
page 1013)
<mode> ::= {SOF | VALue | MERRor}
:SBUS<n>:MANChester:T
RIGger:PATTern:VALue:
DATA <string> (see
page 1014)
:SBUS<n>:MANChester:T
RIGger:PATTern:VALue:
DATA? (see page 1014)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:MANChester:T
RIGger:PATTern:VALue:
WIDTh <width> (see
page 1015)
:SBUS<n>:MANChester:T
RIGger:PATTern:VALue:
WIDTh? (see page 1015)
<width> ::= integer from 4 to 128
in NR1 format
:SBUS<n>:MANChester:T
SIZe <#bits> (see
page 1016)
:SBUS<n>:MANChester:T
SIZe? (see page 1016)
<#bits> ::= from 0-32, in NR1
format
:SBUS<n>:MANChester:W
SIZe <#bits> (see
page 1017)
:SBUS<n>:MANChester:W
SIZe? (see page 1017)
<#bits> ::= from 2-32, in NR1
format
Table 36 :SBUS<n>:MANChester Commands Summary (continued)
Command Query Options and Query Returns
Table 37 :SBUS<n>:NRZ Commands Summary
Command Query Options and Query Returns
:SBUS<n>:NRZ:BASE
<base> (see page 1020)
:SBUS<n>:NRZ:BASE?
(see page 1020)
<base> ::= {HEX | DECimal |
ASCii}
:SBUS<n>:NRZ:BAUDrate
<baudrate> (see
page 1021)
:SBUS<n>:NRZ:BAUDrate
? (see page 1021)
<baudrate> ::= integer from 5000
to 5000000 in 100 b/s increments
