Commands Quick Reference 5
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 179
:SBUS<n>:NRZ:BITorder
<bitorder> (see
page 1022)
:SBUS<n>:NRZ:BITorder
? (see page 1022)
<bitorder> ::= {MSBFirst |
LSBFirst}
:SBUS<n>:NRZ:DISPlay
<format> (see
page 1023)
:SBUS<n>:NRZ:DISPlay?
(see page 1023)
<format> ::= {BIT | WORD}
:SBUS<n>:NRZ:DSIZe
<#words> (see
page 1024)
:SBUS<n>:NRZ:DSIZe?
(see page 1024)
<#words> ::= from 1-255, in NR1
format
:SBUS<n>:NRZ:FSIZe
<#bits> (see
page 1025)
:SBUS<n>:NRZ:FSIZe?
(see page 1025)
<#bits> ::= from 2-255, in NR1
format
:SBUS<n>:NRZ:HSIZe
<#bits> (see
page 1026)
:SBUS<n>:NRZ:HSIZe?
(see page 1026)
<#bits> ::= from 0-32, in NR1
format
:SBUS<n>:NRZ:IDLE:BIT
S <#bits> (see
page 1027)
:SBUS<n>:NRZ:IDLE:BIT
S? (see page 1027)
<#bits> ::= minimum idle time in
terms of bit width, from 1.50 to
32.0, in NR3 format.
:SBUS<n>:NRZ:IDLE:STA
Te <state> (see
page 1028)
:SBUS<n>:NRZ:IDLE:STA
Te? (see page 1028)
<state> ::= {LOW | HIGH}
:SBUS<n>:NRZ:LOGic
<logic> (see
page 1029)
:SBUS<n>:NRZ:LOGic?
(see page 1029)
<logic> ::= {HIGH | LOW}
:SBUS<n>:NRZ:SOURce
<source> (see
page 1030)
:SBUS<n>:NRZ:SOURce?
(see page 1030)
<source> ::= {CHANnel<n> |
DIGital<d>}
:SBUS<n>:NRZ:STARt
<#bits> (see
page 1031)
:SBUS<n>:NRZ:STARt?
(see page 1031)
<#bits> ::= from 0-255, in NR1
format
:SBUS<n>:NRZ:TRIGger
<mode> (see page 1032)
:SBUS<n>:NRZ:TRIGger?
(see page 1032)
<mode> ::= {SOF | VALue}
:SBUS<n>:NRZ:TRIGger:
PATTern:VALue:DATA
<string> (see
page 1033)
:SBUS<n>:NRZ:TRIGger:
PATTern:VALue:DATA?
(see page 1033)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:NRZ:TRIGger:
PATTern:VALue:WIDTh
<width> (see
page 1034)
:SBUS<n>:NRZ:TRIGger:
PATTern:VALue:WIDTh?
(see page 1034)
<width> ::= integer from 4 to 128
in NR1 format
Table 37 :SBUS<n>:NRZ Commands Summary (continued)
Command Query Options and Query Returns
