180 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
5 Commands Quick Reference
:SBUS<n>:NRZ:TSIZe
<#bits> (see
page 1035)
:SBUS<n>:NRZ:TSIZe?
(see page 1035)
<#bits> ::= from 0-32, in NR1
format
:SBUS<n>:NRZ:WSIZe
<#bits> (see
page 1036)
:SBUS<n>:NRZ:WSIZe?
(see page 1036)
<#bits> ::= from 2-32, in NR1
format
Table 37 :SBUS<n>:NRZ Commands Summary (continued)
Command Query Options and Query Returns
Table 38 :SBUS<n>:SENT Commands Summary
Command Query Options and Query Returns
:SBUS<n>:SENT:CLOCk
<period> (see
page 1040)
:SBUS<n>:SENT:CLOCk?
(see page 1040)
<period> ::= the nominal clock
period (tick), from 500 ns to 300
us, in NR3 format.
:SBUS<n>:SENT:CRC
<format> (see
page 1041)
:SBUS<n>:SENT:CRC?
(see page 1041)
<format> ::= {LEGacy |
RECommended}
:SBUS<n>:SENT:DISPlay
<base> (see page 1042)
:SBUS<n>:SENT:DISPlay
? (see page 1042)
<base> ::= {HEX | DECimal |
SYMBolic}
:SBUS<n>:SENT:FORMat
<decode> (see
page 1044)
:SBUS<n>:SENT:FORMat?
(see page 1044)
<decode> ::= {NIBBles | FSIGnal |
FSSerial | FESerial | SSERial |
ESERial}
:SBUS<n>:SENT:IDLE
<state> (see
page 1046)
:SBUS<n>:SENT:IDLE?
(see page 1046)
<state> ::= {LOW | HIGH}
:SBUS<n>:SENT:LENGth
<#_nibbles> (see
page 1047)
:SBUS<n>:SENT:LENGth?
(see page 1047)
<#_nibbles> ::= from 1-6, in NR1
format.
:SBUS<n>:SENT:PPULse
{{0 | OFF} | {1 | ON}
| SPC} (see page 1048)
:SBUS<n>:SENT:PPULse?
(see page 1048)
{0 | 1 | SPC}
:SBUS<n>:SENT:SIGNal<
s>:DISPlay {{0 | OFF}
| {1 | ON}} (see
page 1050)
:SBUS<n>:SENT:SIGNal<
s>:DISPlay? (see
page 1050)
<s> ::= 1-6, in NR1 format.
{0 | 1}
:SBUS<n>:SENT:SIGNal<
s>:LENGth <length>
(see page 1051)
:SBUS<n>:SENT:SIGNal<
s>:LENGth? (see
page 1051)
<s> ::= 1-6, in NR1 format.
<length> ::= from 1-24, in NR1
format.
