Table 61 :TIMebase Commands Summary
Command Query Options and Query Returns
:TIMebase:MODE
<value> (see
page 1283)
:TIMebase:MODE? (see
page 1283)
<value> ::= {MAIN | WINDow | XY |
ROLL}
:TIMebase:POSition
<pos> (see page 1284)
:TIMebase:POSition?
(see page 1284)
<pos> ::= time from the trigger
event to the display reference
point in NR3 format
:TIMebase:RANGe
<range_value> (see
page 1285)
:TIMebase:RANGe? (see
page 1285)
<range_value> ::= time for 10 div
in seconds in NR3 format
:TIMebase:REFClock
{{0 | OFF} | {1 |
ON}} (see page 1286)
:TIMebase:REFClock?
(see page 1286)
{0 | 1}
:TIMebase:REFerence
{LEFT | CENTer |
RIGHt | CUSTom} (see
page 1287)
:TIMebase:REFerence?
(see page 1287)
<return_value> ::= {LEFT | CENTer
| RIGHt | CUSTom}
:TIMebase:REFerence:L
OCation <loc> (see
page 1288)
:TIMebase:REFerence:L
OCation? (see
page 1288)
<loc> ::= 0.0 to 1.0 in NR3
format
:TIMebase:SCALe
<scale_value> (see
page 1289)
:TIMebase:SCALe? (see
page 1289)
<scale_value> ::= time/div in
seconds in NR3 format
:TIMebase:VERNier {{0
| OFF} | {1 | ON}}
(see page 1290)
:TIMebase:VERNier?
(see page 1290)
{0 | 1}
:TIMebase:WINDow:POSi
tion <pos> (see
page 1291)
:TIMebase:WINDow:POSi
tion? (see page 1291)
<pos> ::= time from the trigger
event to the zoomed view
reference point in NR3 format
:TIMebase:WINDow:RANG
e <range_value> (see
page 1292)
:TIMebase:WINDow:RANG
e? (see page 1292)
<range value> ::= range value in
seconds in NR3 format for the
zoomed window
:TIMebase:WINDow:SCAL
e <scale_value> (see
page 1293)
:TIMebase:WINDow:SCAL
e? (see page 1293)
<scale_value> ::= scale value in
seconds in NR3 format for the
zoomed window
