268 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
7 Root (:) Commands
:DIGitize
(see page 1610)
Command Syntax
:DIGitize [<source>[,..,<source>]]
<source> ::= {CHANnel<n> | FUNCtion<m> | MATH<m> | SBUS{1 | 2}}
for the DSO models
<source> ::= {CHANnel<n> | DIGital<d> | POD{1 | 2}
| BUS{1 | 2} | FUNCtion<m> | MATH<m> | SBUS{1 | 2}}
for the MSO models
<n> ::= 1 to (# analog channels) in NR1 format
<d> ::= 0 to (# digital channels - 1) in NR1 format
<m> ::= 1 to (# math functions) in NR1 format
The <source> parameter may be repeated up to 5 times.
The :DIGitize command is a specialized RUN command. It causes the instrument
to acquire waveforms according to the settings of the :ACQuire commands
subsystem. When the acquisition is complete, the instrument is stopped.
If no argument is given, :DIGitize acquires the channels currently displayed. If no
channels are displayed, all channels are acquired.
See Also • "Introduction to Root (:) Commands" on page 258
• ":RUN" on page 291
• ":SINGle" on page 293
• ":STOP" on page 295
• ":TIMebase:MODE" on page 1283
• Chapter 8, “:ACQuire Commands,” starting on page 299
• Chapter 36, “:WAVeform Commands,” starting on page 1393
The :DIGitize command is only executed when the :TIMebase:MODE is MAIN or WINDow.
To halt a :DIGitize in progress, use the device clear command.
MATH<m> is an alias for FUNCtion<m>.
