Root (:) Commands 7
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 281
Return Format <value><NL>
<value> ::= integer in NR1 format.
See Also • "Introduction to Root (:) Commands" on page 258
• ":CHANnel<n>:PROTection" on page 362
• ":OPEE (Operation Status Enable Register)" on page 278
• ":OPERegister[:EVENt] (Operation Status Event Register)" on page 283
• ":OVLenable (Overload Event Enable Register)" on page 286
• ":OVLRegister (Overload Event Register)" on page 288
• "*STB (Read Status Byte)" on page 250
• "*SRE (Service Request Enable)" on page 248
• ":MTERegister[:EVENt] (Mask Test Event Event Register)" on page 276
9 MTE Mask Test Event A mask test event has occurred.
8-6 --- --- (Not used.)
5Wait
Trig
Wait Trig The trigger is armed (set by the Trigger Armed
Event Register (TER)).
4RUI
Enab
Remote Enabled Shows whether the remote user interface is
enabled.
The front-panel graphical user interface can
disable most of the remote interface, including
the *OPC syntax, for example when:
• a modal dialog box is open
• the user is being prompted
• all segments are being analyzed
• there is a channel overload
• certain compliance applications are running
When disabled, commands or queries are
accepted, but "settings conflict" errors are
returned. The status model is the only part of the
remote user interface that is enabled.
To determine when the remote interface is
re-enabled, you can read this bit or wait for the
event that gets generated when its status goes
from disabled to enabled.
3 Run Running The oscilloscope is running (not stopped).
2-0 --- --- (Not used.)
Table 90 Operation Status Condition Register (continued)
Bit Name Description When Set (1 = High = True), Indicates:
