Siemens SINAMICS S110 - p0767 BI: CU analog input signal source for inversion; CU AI inv S_src; p0768 CU analog input noise suppression window; CU AI window; p0769 BI: CU analog input signal source for enable; CU AI enable; p0771[0...2] CI: Test sockets signal source; Test skt S_src

List of parameters
Parameter
1-151
© Siemens AG 2012 All Rights Reserved
SINAMICS S110 List Manual (LH7), 06/2012, 6SL3097-4AP10-0BP3
Description: Sets the signal source to invert the analog input signal.
Description: Sets the window for noise suppression of the analog input.
Changes less than the window are suppressed.
Note: AI: Analog Input
Description: Sets the signal source to enable the analog input.
Description: Sets the signal source for the signal to be output at the test sockets.
Index: [0] = T0
[1] = T1
[2] = Reserved
Dependency: Can only be set when p0776 = 99.
Refer to: r0772, r0774, p0776, p0777, p0778, p0779, p0780, p0783, p0784, r0786
Description: Displays the actual value of the signal to be output.
p0767 BI: CU analog input signal source for inversion / CU AI inv S_src
CU_S110-CAN,
CU_S110-DP,
CU_S110-PN
Can be changed: U, T Calculated: - Access level: 3
Data type: Unsigned32 / Binary Dynamic index: - Func. diagram: 2040
P-Group: Terminals Units group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - 0
p0768 CU analog input noise suppression window / CU AI window
CU_S110-CAN,
CU_S110-DP,
CU_S110-PN
Can be changed: U, T Calculated: - Access level: 3
Data type: FloatingPoint32 Dynamic index: - Func. diagram: 2040
P-Group: Terminals Units group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0.00 [%] 20.00 [%] 0.00 [%]
p0769 BI: CU analog input signal source for enable / CU AI enable
CU_S110-CAN,
CU_S110-DP,
CU_S110-PN
Can be changed: U, T Calculated: - Access level: 3
Data type: Unsigned32 / Binary Dynamic index: - Func. diagram: 2040
P-Group: Terminals Units group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - 1
p0771[0...2] CI: Test sockets signal source / Test skt S_src
CU_S110-CAN,
CU_S110-DP,
CU_S110-PN
Can be changed: U, T Calculated: - Access level: 2
Data type: Unsigned32 / Integer16 Dynamic index: - Func. diagram: 8134
P-Group: Terminals Units group: - Unit selection: -
Not for motor type: - Scaling: PERCENT Expert list: 1
Min Max Factory setting
- - 0
r0772[0...2] Test sockets output signal / TestSktsSignalVal
CU_S110-CAN,
CU_S110-DP,
CU_S110-PN
Can be changed: - Calculated: - Access level: 2
Data type: FloatingPoint32 Dynamic index: - Func. diagram: 8134
P-Group: Terminals Units group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- [%] - [%] - [%]
