Parameter
List of parameters
1-162
© Siemens AG 2012 All Rights Reserved
SINAMICS S110 List Manual (LH7), 06/2012, 6SL3097-4AP10-0BP3
Example:
p0827[0] = 0: For MDS0, r0830.0 is switched.
p0827[1] = 5: For MDS1, r0830.5 is switched.
Dependency: Refer to: p0826, r0830
Note: A motor is only changed over (a new motor selected) after the pulses have been suppressed.
When the motor data sets are changed over, the following applies:
Bit numbers that are not identical, signify that the motor must be changed over.
Description: Sets the signal source for the feedback signal when changing over the motor.
For p0833.0 = 1 the following applies:
This feedback signal (0/1 edge) is required after a motor changeover to enable the pulses.
Dependency: Refer to: p0833
Notice: The parameter may be protected as a result of p0922 or p2079 and cannot be changed.
Description: Displays the status word of the motor changeover.
These signals can be connected to digital outputs to change over the motor.
Dependency: Refer to: p0827
p0828[0...n] BI: Motor changeover, feedback signal / Mot_chng fdbk sig
SERVO_S110-CAN,
SERVO_S110-DP,
SERVO_S110-PN
Can be changed: C2(3), T Calculated: - Access level: 3
Data type: Unsigned32 / Binary Dynamic index: CDS, p0170 Func. diagram: 8575
P-Group: Motor Units group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - 0
r0830.0...15 CO/BO: Motor changeover, status word / Mot_chngov ZSW
SERVO_S110-CAN,
SERVO_S110-DP,
SERVO_S110-PN
Can be changed: - Calculated: - Access level: 2
Data type: Unsigned16 Dynamic index: - Func. diagram: 8575
P-Group: Displays, signals Units group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Motor selection, bit 0 High Low -
01 Motor selection, bit 1 High Low -
02 Motor selection, bit 2 High Low -
03 Motor selection, bit 3 High Low -
04 Motor selection, bit 4 High Low -
05 Motor selection, bit 5 High Low -
06 Motor selection, bit 6 High Low -
07 Motor selection, bit 7 High Low -
08 Motor selection, bit 8 High Low -
09 Motor selection, bit 9 High Low -
10 Motor selection, bit 10 High Low -
11 Motor selection, bit 11 High Low -
12 Motor selection, bit 12 High Low -
13 Motor selection, bit 13 High Low -
14 Motor selection, bit 14 High Low -
15 Motor selection, bit 15 High Low -
