284 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
7 Root (:) Commands
Return Format <value><NL>
<value> ::= integer in NR1 format.
See Also • "Introduction to Root (:) Commands" on page 258
• ":CHANnel<n>:PROTection" on page 362
• ":OPEE (Operation Status Enable Register)" on page 278
• ":OPERegister:CONDition (Operation Status Condition Register)" on page 280
• ":OVLenable (Overload Event Enable Register)" on page 286
• ":OVLRegister (Overload Event Register)" on page 288
• "*STB (Read Status Byte)" on page 250
• "*SRE (Service Request Enable)" on page 248
9 MTE Mask Test Event A mask test event has occurred.
8-6 --- --- (Not used.)
5Wait
Trig
Wait Trig The trigger is armed (set by the Trigger Armed
Event Register (TER)).
4RUI
Enab
Remote Enabled The remote user interface has gone from a
disabled state to an enabled state.
The front-panel graphical user interface can
disable most of the remote interface, including
the *OPC syntax, for example when:
• a modal dialog box is open
• the user is being prompted
• all segments are being analyzed
• there is a channel overload
• certain compliance applications are running
When disabled, commands or queries are
accepted, but "settings conflict" errors are
returned. The status model is the only part of the
remote user interface that is enabled.
To determine when the remote interface is
re-enabled, you can read this bit or wait for the
event that gets generated when its status goes
from disabled to enabled.
3 Run Running The oscilloscope has gone from a stop state to a
single or running state.
2-0 --- --- (Not used.)
Table 91 Operation Status Event Register (continued)
Bit Name Description When Set (1 = High = True), Indicates:
