Dell Force10 Z9000 - Page 1372

Parameters
ip-address Enter the keyword host followed by the IP address of the host
(configurable hosts is limited to 16).
ipv6-address Enter the keyword host followed by the IPv6 address of the host in the
x:x:x:x::x format.
NOTE: The :: notation specifies successive hexadecimal fields of
zero.
traps (OPTIONAL) Enter the keyword traps to send trap notifications to
the specified host. The default is
traps.
informs (OPTIONAL) Enter the keyword informs to send inform notifications
to the specified host. The default is traps.
version 1 | 2c | 3 (OPTIONAL) Enter the keyword version to specify the security model
followed by the security model version number 1, 2c, or 3:
• Version 1 is the least secure version.
• Version 3 is the most secure of the security modes.
• Version 2c allows transmission of informs and counter 64,
which allows for integers twice the width of what is normally
allowed.
The default is version 1.
auth (OPTIONAL) Enter the keyword auth to specify authentication of a
packet without encryption.
noauth (OPTIONAL) Enter the keyword noauth to specify no authentication
of a packet.
priv (OPTIONAL) Enter the keyword priv to specify both authentication
and then scrambling of the packet.
community-string Enter a text string (up to 20 characters long) as the name of the
SNMP community.
NOTE: For version 1 and version 2c security models, this string
represents the name of the SNMP community. The string can be
set using this command; however, Dell Force10 recommends
setting the community string using the snmp-server
community command before executing this command. For
version 3 security model, this string is the USM user security
name.
udp-port port-
number
(OPTIONAL) Enter the keywords udp-port followed by the port
number of the remote host to use. The range is 0 to 65535. The default
is 162.
notification-type (OPTIONAL) Enter one of the following keywords for the type of trap
to be sent to the host:
• bgp - BGP state change.
• config - copy-configuration traps.
1372
