Dell Force10 Z9000 Reference Guide

Version 8.3.1.0 Introduced on the E-Series.
Usage
Information
The running router sets the remaining time value to the current adjacency hold time. You can
override this setting by implementing this command.
Override the default restart-wait time by entering the no graceful-restart
restart-wait command. When you disable restart-wait, the current adjacency hold
time is used.
Set the t3 timer to adjacency on the restarting router when implementing this command. The
restarting router gets the remaining time value from its peer and adjusts its T3 value so only
when you have configured
graceful-restart t3 adjacency.
Related
Commands
graceful-restart restart-wait – enables the graceful restart maximum wait time before a
restarting peer comes up.
graceful-restart restart-wait
Enable the graceful restart maximum wait time before a restarting peer comes up.
E-Series, S4810
Syntax
NOTE: Set the t3 timer to adjacency on the restarting router when implementing this
command.
graceful-restart restart-wait seconds
To return to the default, use the no graceful-restart restart-wait command.
Parameters
seconds Enter the graceful restart time in seconds. The range is 5 to 300
seconds. The default is 30 seconds.
Defaults 30 seconds
Command Modes ROUTER ISIS
Command History
Version 8.3.12.0 Introduced on the S4810.
Version 8.3.1.0 Introduced on the E-Series.
Related
Commands
graceful-restart t3 – configures the overall wait time before graceful restart completes.
871

Dell Force10 Z9000 Specifications

General

Switching Capacity	2.56 Tbps
Power Supply	Dual, hot-swappable
MTBF	200, 000 hours
Ports	32 x 40GbE QSFP+
Cooling	Front-to-back airflow
Form Factor	Fixed
Jumbo Frame Support	Up to 9216 bytes
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
MAC Address Table Size	128K
Dimensions (HxWxD)	3.45 in x 17.32 in x 20.0 in
