encrypted (OPTIONAL) Enter the keyword encrypted to specify the password
appear in encrypted format (a series of digits, masking the true
characters of the string).
auth (OPTIONAL) Enter the keyword auth to specify authentication of a
packet without encryption.
md5 | sha (OPTIONAL) Enter the keyword md5 or sha to designate the
authentication level.
• md5 — Message Digest Algorithm
• sha — Secure Hash Algorithm
auth-password
(OPTIONAL) Enter a text string (up to 20 characters long) password
that enables the agent to receive packets from the host. Minimum: 8
characters long.
priv des56 (OPTIONAL) Enter the keywords priv des56 to initiate a privacy
authentication level setting using the CBC-DES privacy authentication
algorithm (des56).
priv password
(OPTIONAL) Enter a text string (up to 20 characters long) password
that enables the host to encrypt the contents of the message it sends
to the agent. Minimum: 8 characters long.
access
access-
list-name
(Optional) Enter the standard IPv4 access list name (a string up to 16
characters long).
ipv6
access-list-
name
(Optional) Enter the keyword ipv6 followed by the IPv6 access list
name (a string up to 16 characters long).
access-list-name
ipv6
access-list-
name
(Optional) Enter both an IPv4 and IPv6 access list name.
Defaults As above.
Command Modes CONFIGURATION
Command History
Version 8.3.11.1 Introduced on the Z9000.
Version 8.3.7.0 Introduced on the S4810.
Version 7.6.1.0 Introduced on the S-Series.
Version 7.5.1.0 Introduced on the C-Series.
E-Series legacy
command
Usage
Information
NOTE: For IPv6 ACLs, only IPv6 and UDP types are valid for SNMP. TCP and ICMP rules
are not valid for SNMP. In IPv6 ACLs port rules are not valid for SNMP.
No default values exist for authentication or privacy algorithms and no default password exists.
If you forget a password, you cannot recover it; the user must be reconfigured. You can specify
either a plain-text password or an encrypted cypher-text password. In either case, the
1377
