router Reviewing and Configuring Routing
Enterasys Matrix DFE-Gold Series Configuration Guide 2-103
router
UsethiscommandtoenterrouterCLImode.
Syntax
router
Parameters
None.
Defaults
None.
Mode
Switchcommand,Read‐Write.
Example
Thisexampleshowshowtoenableroutingonthisrouter:
Matrix(su)->router
Matrix(rw)->Router>
Enabling Router Configuration Modes
TheMatrixCLIprovidesdifferentmodesofrouteroperationforissuingasubsetofcommands
fromeachmode.Table 2‐9describesthesemodesofoperation.
Note: The command prompts used as examples in Tab le 2- 9 and throughout this guide show switch
operation for a user in Read-Write (rw) access mode, and a system where module 1 and VLAN 1
have been configured for routing. The prompt changes depending on your current configuration
mode, the specific module, and the interface types and numbers configured for routing on your
system.
Table 2-9 Router CLI Configuration Modes
Use this mode... To... Access method... Resulting Prompt...
Privileged EXEC
Mode
• Set system
operating
parameters
• Show configuration
parameters
• Save/copy
configurations
From the switch CLI:
1. Type router, then
2. Type enable.
Matrix>Router>
Matrix>Router#
Global Configuration
Mode
Set system-wide
parameters.
Type configure
terminal from
Privileged EXEC mode.
Matrix>router(config)#
Interface
Configuration Mode
Configure router
interfaces.
Type interface vlan or
interface loopback and
the interface’s id from
Global Configuration
mode.
Matrix>router
(config-if(Vlan 1 | Lpbk 1))#
