Link Layer Discovery Protocol and LLDP-MED set lldp port location-info

3-30 Discovery Protocols Configuration

Example

ThisexampleenablestransmittingLLDP‐MEDtrapsonportsge.1.1throughge.1.6.

Matrix(rw)->set lldp port med-trap enable ge.1.1-6

set lldp port location-info

UsethiscommandtoconfigureLLDP‐MEDlocationinformationonaportorrangeofports.

Currently,onlyEmergencyCallServices(ECS)EmergencyLocationIdentificationNumber(ELIN)

issupported.

Syntax

set lldp port location-info elin elin-string port-string

Parameters

Defaults

None.

Mode

Switchcommand,Read‐Write.

Example

Afteryouconfigurealocationinformationvalue,youmustalsoconfiguretheporttosendthe

LocationInformationTLVwiththesetlldpporttx‐tlvcommand.Thisexampleconfiguresthe

ELINidentifier5551234567onportsge.1.1throughge.1.6andthenconfigurestheportstosend

theLocationInformationTLV.

Matrix(rw)->set lldp port location-info 5551234567 ge.1.1-6

Matrix(rw)->set lldp port tx-tlv med-loc ge.1.1-6

set lldp port tx-tlv

UsethiscommandtoselecttheoptionalLLDPandLLDP‐MEDTLVstobetransmittedin

LLDPDUsbythespecifiedportorports.Usetheshowlldpportlocal‐infocommandtodisplay

thevaluesoftheseTLVsfortheport.

Syntax

set lldp port tx-tlv {[all] | [port-desc] [sys-name] [sys-desc] [sys-cap] [mgmt-

addr] [vlan-id] [stp] [lacp] [gvrp] [mac-phy] [poe] [link-aggr] [max-frame] [med-

cap] [med-pol] [med-loc] [med-poe]} port-string

elin SpecifiesthattheECSELINdataformatistobeused.

elin-string Specifies thelocationidentifier.Valuecanbefrom10to25num erical

characters.

port-string Specifiestheportorrangeofportstobeaffected.
