set port mirroring Configuring Port Mirroring
Enterasys Matrix DFE-Gold Series Configuration Guide 4-53
Parameters
None.
Defaults
None.
Mode
Switchcommand,Read‐Only.
Example
Thisexampleshowshowtodisplayportmirroring information.Inthiscase,fe.1.4isconfiguredas
asourceportandfe.1.11isatarget,butmirroringisnotcurrentlyenabledbetweentheports:
Matrix(rw)->show port mirroring
Port Mirroring
==============
Source Port = fe.1.4
Target Port = fe.1.11
Frames Mirrored = Rx and Tx
Port Mirroring status disabled.
set port mirroring
Usethiscommandtocreateanewmirroringrelationshiportoenableordisableanexisting
mirroringrelationshipbetweentwoports.
Syntax
set port mirroring{create| disable| enable}| igmp‐mcast{enable|disable}source
destination
[both| rx| tx]
Parameters
create|disable|
enable
Creates,disablesorenablesmirroringsettingsonthespecifiedports.
igmp‐mcastenable|
disable
EnablesordisablesthemirroringofIGMPmulticastframes.
source Specifiesthesourceportdesignation.Thisistheportonwhichthe
trafficwillbemonitored.Foradescriptionofporttypesthat
can
participateinmirroring,referto“SupportedMirrors”onpage 4‐52.For
adetaileddescriptionofpossibleport‐stringvalues,referto“PortString
SyntaxUsedintheCLI”onpage 4‐2.
destination Specifiesthetargetportdesignation.Thisisthe portthatwillduplicate
or“mirror”allthe
trafficonthemonitoredport.Foradetailed
descriptionofpossibleport‐stringvalues,referto“PortStringSyntax
UsedintheCLI”onpage 4 ‐2.
both|rx|tx (Optional)Specifiesthatframesreceivedandtransmittedbythesource
port,onlyframesreceived,oronlyframestransmittedwillbe
mirrored.
