Enterasys Matrix DFE-Gold Series User Manual

Port Configuration Summary
4-2 Port Configuration
Switch Ports
TheMatrixSeriesmodulesandstandalonedeviceshavefixedfrontpanelswitchportsand,
dependingonthemodel,optionalexpansionmoduleslots.Thenumberingschemeusedto
identifytheswitchportsonthefrontpanelandtheexpansionmodule(s)installedisinterface‐type
dependentandisalsodependentuponthechassis
inwhichthemodule(s)areinstalled.
Port String Syntax Used in the CLI
Commandsrequiringaport‐stringparameterusethefollowingsyntaxtodesignateporttype,slot
location,andportnumber:
port type.slot location.port number
Whereporttypecanbe:
fefor100‐MbpsEthernet
gefor1‐GbpsEthernet
tgfor10‐GbpsEthernet
comforCOM(console)port
hostforthehostport
vlanforvlaninterfaces
lagforIEEE802.3li nkaggregationports
lpbkforloopbackinterfaces,or
loforthelocal(softwareloopback)interface
bpforFTM1
backplaneports
pcfortheinternalportswhichconnecttotheon‐boardprocessorofaninstalledMatrixSecurity
Module
rtrforrouterinterface
SlotlocationformodulesinstalledinaMatrixN7orE7chassiscanbe:
0through7,with0designatingvirtualsystemports(lag,vlan,host,loopback),and
1designating
theleft‐mostmoduleslotinthechassis.
SlotlocationformodulesinstalledinaMatrixN3orN5chassiscanbe:
0through3or0through5,with0designatingvirtualsystemports(lag,vlan,host,loopback),and
1designatingthelowestmoduleslotinthechassis.
Portnumbercanbe:
Anyportnumberinaslotlocation.Thehighestvalidportnumberisdependentonthenumberof
portsinaslotlocationandtheporttype.
Forexample:
Ifamoduleinslot1has48,100MbpsFastEthernetfrontpanelports,andanuplinkinterface
with
6MiniGBICs,therangeofportnumberdesignationsusedintheCLIcommandwouldbe:
fe.1.1throughfe.1.48forthe48100MbpsFastEthernetfrontpanelports,and
ge.1.1throughge.1.6forthe6MiniGBICuplinkports.
Iftheuplinkhasthesametype(fe)portsas the
frontpanel,thenumberingcontinueswiththeport
numberfe.1.49.
Examples
Thisexampleshowstheport‐stringsyntaxfors pecifyingthe100‐MbpsEthernetports1through10
inthemoduleinchassisslot 1.
Note: You can use a wildcard (*) to indicate all of an item. For example, fe.3.* would represent all
100Mbps Ethernet (fe) ports in the module in slot 3.
