Enterasys Matrix DFE-Gold Series User Manual

set router limits (LSNAT) Configuring Load Sharing Network Address Translation (LSNAT)
Enterasys Matrix DFE-Gold Series Configuration Guide 19-33
Usage
ThiscommandmustbeexecutedfromtheswitchCLI.
Examples
Thisexampledisplaysallrouterlimitsforthissystem:
Matrix(su)->show router limits
LSNAT maximum Bindings - 32000 (default)
LSNAT Cache size - 2000 (default)
LSNAT maximum Configs - 50 (default)
NAT maximum Bindings - 32000 (default)
NAT Cache size - 2000 (default)
NAT maximum dynamic mapping Configs - 10 (default)
NAT maximum static mapping Configs - 50 (default)
NAT maximum Interface Configs - 103 (default)
NAT maximum global address Configs - 1000 (default)
NAT maximum global port Configs - 32000 (default)
Route Table Limit - 12000 (default)
TWCB maximum Bindings - 32000 (default)
TWCB Cache size - 2000 (default)
TWCB maximum Configs - 1 (default)
ThisexampledisplaystheLSNATcache‐sizelimitforthissystem:
Matrix(su)->show router limits lsnat-cache
LSNAT Cache size - 2000 (default)
set router limits (LSNAT)
UsethiscommandtosetLSNATrouterlimits.
Syntax
set router limits [lsnat-bindings lsnat-bindings] | [lsnat-cache lsnat-cache] |
[lsnat-configs lsnat-configs]
Parameters
lsnat‐bindings
lsnat‐bindings
(Optional)SetstheLSNATmaximumbindingslimit.
lsnat‐cachelsnat‐cache (Optional)SetstheLSNATcachesizelimit.
lsnat‐configs
lsnat‐configs
(Optional)SetstheLSNATconfigurationlimitforthenumberofserver
farms,virtualservers,directaccessentries,realservers,andclient
accessentries.
The lsnat-configs value can range from 1 to 50. The number specified
will have the following effect:
• 1 to 50 server farms, virtual servers, and direct access entries can be
configured
• 10 to 500 real servers and client access entries can be configured
