show support Reviewing and Configuring Routing
Enterasys Matrix DFE-Gold Series Configuration Guide 2-101
TheexampleinFigure 2‐8showshowto:
•Enableroutingforthisrouter.
• ConfigureVLAN1onIPaddress182.127.63.1255.255.255.0astheroutinginterface.
Figure 2-8 Enabling the Switch for Routing
Matrix(rw)->router
Matrix>router>enable
Matrix>router#configure terminal
Enter configuration commands:
Matrix>Router(config)#interface vlan 1
Matrix>Router(config-if(Vlan 1))#ip address 182.127.63.1 255.255.255.0
Matrix>Router(config-if(Vlan 1))#no shutdown
Reviewing and Configuring Routing
Purpose
Toreviewandconfigurerouting.
Commands
Step 3 Enable global router
configuration mode.
configure terminal Router:
Matrix>Router#
“Enabling Router
Configuration
Modes” on
page 2-103
Step 4 Enable interface
configuration mode
using the interface of
the routing module.
interface {vlan vlan-
id | loopback
loopback-id
Router:
Matrix>
Router(config)#
“interface” on
page 16-3
Step 5 Assign an IP address to
the routing interface.
ip address {
ip-
address ip-mask}
Router:
Matrix>Router
(config-if (Vlan 1 |
Lpbk 1))#
“ip address” on
page 16-6
Step 6 Enable the interface for
IP routing.
no shutdown Router:
Matrix>Router
(config-if (Vlan 1 |
Lpbk 1))#
“no shutdown” on
page 16-7
Table 2-8 Enabling the Switch for Routing
To do this task
Type this
command... At this prompt... For details see...
For information about... Refer to page...
show router 2-102
clear router 2-102
router 2-103
