Configuring Debug IP Packet debug ip packet access-group

16-30 IP Configuration

Configuring Debug IP Packet

Purpose

DebugIPpacketisanIPbasedpacketmonitorthatallowsforthemonitoringofallIPtraffic

receivedandtransmittedfromanN‐Seriesrouterforwardingengine.DebugIPPacketuses

SYSLOGmessagestodisplaypacketinformation.Packetfilteringtakesplacebyassigningarouter

accessgrouptothedebug

ippacketcommandandisbasedonthegroup sACLentries.This

utilitydisplaysmatchingframesforthedefinedsignaturebeingprocessedinthesoftpathofthe

router.Itisdesirablethatthenumberofrulesassignedtotheaccessgroupbelimitedsoasto

minimizetheimpact

ontheforwardingsystemperformance.Bydefaulttheutilitydisplaysa

subsetofavailableinformation.Averboseoptionprovidesdetailedpacketinformation.Options

areavailabletoboththrottlethenumberofpacketspersecondandlimitthenumberofpackets

perboard.

Commands

debug ip packet access-group

UsethiscommandtoenablethedebugIPpacketutilityformonitoringofIPpacketsbasedupon

theassociatedaccess‐group.

Syntax

debug ip packet access-group access-group [throttle throttle] [limit limit]

[verbose]

Parameters

Defaults

throttle=10,limit=30.

For information about... Refer to page...

debug ip packet access-group 16-30

debug ip packet restart 16-31

show debugging 16-32

no debug ip packet 16-32

access‐group Specifiesthenameoftheaccessgroupusedtofilterpacketsforthis

command.

throttlethrottle (Optional)Specifiesthenumberoffilteredpacketspersecondtobe

displayed.ValidValues:2‐100

limitlimi t (Optional)Specif iesthenumberofpacketsperboardtobedisplayed.

ValidValues:0‐1000(0

=nolimitapplied)

verbose (Optional)Specifiesdetailedpacketinformationlevel.

Enterasys Matrix DFE-Gold Series User Manual
