set cep detection-id porthigh | portlow Configuring Convergence End Points (CEP) Phone Detection
Enterasys Matrix DFE-Gold Series Configuration Guide 25-47
Parameters
Defaults
None.
Mode
Switchcommand,Read‐Write.
Usage
ThiscommandappliesonlytoSiemens,H.323,andSIPphonedetection.Ciscodetectionuses
CiscoDPasitsdiscoverymethod.
IfanIPaddressisnotsetforaphonedetectiongroupasdescribedin“setcepdetection‐id
address”onpage 25‐46,thiswillconfiguredetectiononUDPand/orTCP
portsusingaportrange
definedwiththesetcep detection‐idporthigh|portlowcommandasdescribedin“setcep
detection‐idporthigh|portlow”onpage 25‐47.
Example
Thisexampleshowshowtoenableboth TCPandUDPconvergenceendpointsdetectionforCEP
detectiongroup1:
Matrix>set cep detection-id 1 protocol both
set cep detection-id porthigh | portlow
UsethiscommandtosetthemaximumandminimumportsusedforTCPorUDPconvergence
endpointsdetection.
Syntax
set cep detection-id id { porthigh | portlow } port
Parameters
Defaults
None.
id Specif iesaCEPconfigurationgroupID.Thisgroupmustbecreated
andenabledusingthesetcepdetection‐idcommandasdescribedin
“setcepdetection‐id”onpage 25‐44.Validvaluesare1‐2147483647.
tcp|udp|both|
none
SetstheCEPIPprotocoltypeto
beusedfordetectionas:
•TCP
•UDP
•BothUDPandTCP
• None
id Specif iesaCEPconfigurationgroupID.Thisgroupmustbecreated
andenabledusingthesetcepdetection‐idcommandasdescribedin
“setcepdetection‐id”onpage 25‐44.Validvaluesare1‐2147483647.
porthigh|portlow
port
SpecifiesamaximumorminimumUDPorTCPportfor
CEP
detection.Validvaluesare1‐65535.
