Cisco Discovery Protocol set ciscodp port
3-12 Discovery Protocols Configuration
set ciscodp port
Usethiscommandtosetthestatus,voiceVLAN,extendedtrustmode,andCoSpriorityfor
untrustedtrafficfortheCiscoDiscoveryProtocolononeormoreports.
Syntax
set ciscodp port { [status {disable | enable}] [ vvid {<vlan-id> | none | dot1p |
untagged}] [trust-ext {trusted | untrusted}] [cos-ext value] } <port-string>
Parameters
Defaults
None.
Mode
Switchcommand,Read‐Write.
Usage
ThefollowingpointsdescribehowtheCiscoDPextendedtrustsettingsworkontheMatrix
device.
status SetstheCiscoDPportoperationalstatus.
disable DoesnottransmitorprocessCiscoDPPDUs.
enable TransmitsandprocessesCiscoDPPDUs.
vvid SetstheportvoiceVLANforCiscoDPPDUtransmission.
<vlan‐id>SpecifiestheVLANID,range1
‐4094.
none NovoiceVLANwillbeusedinCiscoDPPDUs.
dot1p Instructsattachedphonetosend802.1ptaggedframes.
untagged Instructsattachedphonetosenduntaggedframes.
trust‐ext Setstheextendedtrustmodeontheport.
trusted Instructsattachedphonetoallowthedeviceconnectedtoittotransmit
trafficcontaininganyCoS
orLayer2802.1pmarking.Thisisthedefault
value.
untrusted Instructsattachedphonetooverwritethe802.1ptagoftraffic
transmittedbythedeviceconnectedtoitto0,bydefault,ortothevalue
configuredwiththecos‐extparameter.
cos‐extvalue Instructsattachedphonetooverwritethe802.1p
tagoftraffic
transmittedbythedeviceconnectedtoitwiththespecifiedvalue,when
thetrustmodeoftheportissettountrusted.Valuecanrangefrom0to
7,with0indicatingthelowestpriority.
port‐string Specifiestheport(s)onwhichstatuswillbeset.Fora
detailed
descriptionofpossibleport‐stringvalues,referto“PortStringSyntax
UsedintheCLI”onpage 4 ‐2.
Note: The Cisco Discovery Protocol must be globally enabled using the set ciscodp status
command as described in “set ciscodp status” on page 3-10 before operational status can be set on
individual ports.
