Configuring Network Address Translation (NAT)
18-2 Network Address Translation (NAT) Configuration
NATworkswithDNSbyhavingtheDNSApplicationSpecificGateway(ALG)translatean
addressthatappearsinaDomainNameSystemresponsetoanameorinverselookup.
NATworkswithFTPbyhavingtheFTPALGtranslatetheFTPcontrolpayload.BothFTPPORT
CMDpacketsandPASVpackets,
containingIPaddressinformationwithinthedataportion,are
supported.
TheNATimplementationalsosupportsthetranslationoftheIPaddressembeddedinthedata
portionoffollowingtypesofICMPerrormessage:destinationun reachable(type3),sourcequench
(type4),redirect(type5),timeexceeded(type11)andparameterproblem(type12).
Purpose
TodisplayandsetNATandNAPTconfigurationincludingdynamicpools,staticanddynamic
NATconfigurations,FTPcontrolport,ForceFlows,maximumentriesandtimeoutvalues,and
clearactivetranslations.
NAT Configuration Task List and Commands
Table 18‐1liststhemandatoryandoptionaltasksandcommandsforconfiguringNATonthe
EnterasysMatrixSeriesdevice.Commandsaredescribedintheassociatedsectionsasshown.
Table 18-1 NAT Configuration Task List and Commands
Task Use these commands...
Enable NAT on an inside or outside interface. ip nat {inside | outside}
Define a NAT address pool. ip nat pool name start-ip-address
end-ip-address {netmask netmask |
prefix-length prefix-length}
Enable dynamic translation of inside source addresses. ip nat inside source [list access-list] pool
pool-name [overload | interface vlan vlan-id
[overload]]
Enable static NAT translation of inside source addresses. ip nat inside source static local-ip global-ip
Enable static NAPT translation of inside source
addresses.
ip nat inside source static {tcp | udp} local-ip
local-port global-ip global-port
Specify the NAT FTP control port. ip nat ftp-control-port port-number
Block the defined inside IP addresses from ever
appearing on an outside interface.
ip nat secure-plus
Configure the maximum number of translation entries. ip nat translation max-entries number
Configure NAT translation timeout values. ip nat translation {timeout | udp-timeout |
tcp-timeout | icmp-timeout | dns-timeout |
ftp-timeout} seconds
Display active NAT translations. show ip nat translations [verbose]
Display NAT translation statistics. show ip nat statistics [verbose]
Clear dynamic NAT translations. clear ip nat translation
Clear a specific active simple NAT translation. clear ip nat translation inside global-ip
local-ip
Clear a specific dynamic NAT translation. clear ip nat translation {tcp | upd} inside
global-ip global-port local-ip local-port
