Enterasys Matrix DFE-Gold Series User Manual

show policy rule Assigning Classification Rules to Policy Profiles
Enterasys Matrix DFE-Gold Series Configuration Guide 8-9
|PID |Rule Type |Rule Data |Mk|PortStr |RS|ST|S|T|D|VLAN|CoS |U|
| 1 |Ether |32923 (0x809B) |16|All | A|NV|Y|Y| | 105| |?|
| 1 |Ether |33011 (0x80F3) |16|All | A|NV|Y|Y| | 105| |?|
| 1 |Ether |33079 (0x8137) |16|All | A|NV|Y|Y| | 101| |?|
| 1 |Ether |33080 (0x8138) |16|All | A|NV|Y|Y| | 101| |?|
| 1 |Ether |33276 (0x81FC) |16|All | A|NV|Y|Y| |drop| |?|
| 2 |Ether |32923 (0x809B) |16|All | A|NV|Y|Y| | 105| |?|
| 2 |Ether |33011 (0x80F3) |16|All | A|NV|Y|Y| | 105| |?|
| 2 |Ether |33079 (0x8137) |16|All | A|NV|Y|Y| | 101| |?|
Thisexampleshowshowtodisplayadminruleinformationforthepolicyprofilewithindex
number 1:
Matrix(rw)->show policy rule admin-pid 1
|Admin|Rule Type |Rule Data |Mk|PortStr |RS|ST|S|T|D|dPID|aPID|U|
|admin|Port |fe.1.1 |16|fe.1.1 | A|NV| | | | | 1|?|
|admin|Port |fe.1.2 |16|fe.1.2 | A|NV| | | | | 1|?|
|admin|Port |fe.1.3 |16|fe.1.3 | A|NV| | | | | 1|?|
|admin|Port |fe.1.4 |16|fe.1.4 | A|NV| | | | | 1|?|
|admin|Port |fe.1.5 |16|fe.1.5 | A|NV| | | | | 1|?|
|admin|Port |fe.1.6 |16|fe.1.6 | A|NV| | | | | 1|?|
Table 8‐2providesanexplana tion ofthecommandoutput.
Table 8-2 show policy rule Output Details
Output... What it displays...
PID Profile profile index number, indicating a classification rule is displayed.
Assigned to this classification rule with the set policy profile
command (“set policy profile” on page 8-3).
Admin Indicates an admin rule is displayed.
Rule Type Whether the rule protocol-based or port-based. Refer to Ta bl e 8- 3 for
valid classification types.
Rule Data Rule data value. Refer to Ta bl e 8-3 for valid values for each
classification type.
Mk Rule data mask. Refer to Table 8-3 for valid values for each
classification data value.
PortStr Ingress port(s) to which this rule applies.
RS Whether or not the status of this rule is active (A), not in service or not
ready.
ST Whether or not this rule’s storage type is non-volatile (NV) or volatile
(V).
Vlan VLAN ID to which this rule applies and whether or not matching
packets will be dropped or forwarded.
CoS Class of Service value to which this rule applies.
dPID Whether or not this is a dynamic profile ID.
aPID Whether or not this is an administrative profile index ID.
