show spantree stats Configuring Spanning Tree Bridge Parameters
Enterasys Matrix DFE-Gold Series Configuration Guide 6-7
Bridge Max Age - 20 sec
Bridge Hello Time - 2 sec
Bridge Forward Delay - 15 sec
Topology Change Count - 7
Time Since Top Change - 00 days 03:19:15
Max Hops - 20
Table 6‐1showsadetailedexplanationofcommandoutput.
Table 6-1 show spantree Output Details
Output... What it displays...
Spanning tree instance Spanning Tree ID.
Spanning tree status Whether Spanning Tree is enabled or disabled.
Designated Root MacAddr MAC address of the designated Spanning Tree root bridge.
Designated Root Port Port through which the root bridge can be reached.
Designated Root Priority Priority of the designated root bridge.
Designated Root Cost Total path cost to reach the root.
Root Max Age Amount of time (in seconds) a BPDU packet should be considered
valid.
Root Hello Time Interval (in seconds) at which the root device sends BPDU (Bridge
Protocol Data Unit) packets.
Root Forward Delay Amount of time (in seconds) the root device spends in listening or
learning mode.
Bridge ID MAC Address Unique bridge MAC address, recognized by all bridges in the network.
Bridge ID Priority Bridge priority, which is a default value, or is assigned using the set
spantree priority command. For details, refer to “set spantree priority”
on page 6-20.
Bridge Max Age Maximum time (in seconds) the bridge can wait without receiving a
configuration message (bridge “hello”) before attempting to
reconfigure. This is a default value, or is assigned using the set
spantree maxage command. For details, refer to “set spantree
maxage” on page 6-26.
Bridge Hello Time Amount of time (in seconds) the bridge sends BPDUs. This is a default
value, or is assigned using the set spantree hello command. For
details, refer to “set spantree hello” on page 6-24.
Bridge Forward Delay Amount of time (in seconds) the bridge spends in listening or learning
mode. This is a default value, or is assigned using the set spantree
fwddelay command. For details, refer to “set spantree fwddelay” on
page 6-27.
Topology Change Count Number of times topology has changed on the bridge.
Time Since Top Change Amount of time (in days, hours, minutes and seconds) since the last
topology change.
Max Hops Maximum number of hops information for a particular Spanning Tree
instance may traverse (via relay of BPDUs within the applicable MST
region) before being discarded. This is a default value, or is assigned
using the set spantree mashops command. For details, refer to “set
spantree maxhops” on page 6-35.
