Enterasys Matrix DFE-Gold Series User Manual

Configuring LACP set port lacp
4-66 Port Configuration
Matrix(rw)->show port lacp port fe.1.12 status summary
Port AggrActor System Partner System
Pri: System ID: Key: Pri: System ID: Key:
fe.1.12 none [(32768,00e0639db587,32768),(32768,000000000000, 1411)]
ThisexampleshowshowtodisplayLACPcountersforportfe.1.12:
Matrix(rw)->show port lacp port fe.1.12 counters
Port Instance: fe.1.12
LACPDUsRx: 0 MarkerPDUsRX: 0
LACPDUsTx: 0 MarkerPDUsTx: 0
IllegalRx: 0 MarkerResponsePDUsRx: 0
UnknownRx: 0 MarkerResponsePDUsTx: 0
ActorSyncTransitionCount: 0 PartnerSyncTransitionCount: 0
ActorChangeCount: 1 PartnerChangeCount: 0
ActorChurnCount: 0 PartnerChurnCount: 0
ActorChurnState: ChurnMonitor PartnerChurnState: ChurnMonitor
MuxState: detached
MuxReason: BEGIN = TRUE
set port lacp
Usethiscommandtosetlinkaggregationparametersfor oneormoreports.
Syntax
set port lacp port port-string {[aadminkey aadminkey] [aportpri aportpri] [asyspri
asyspri] [aadminstate { lacpactive | lacptimeout | lacpagg | lacpsync | lacpcollect
| lacpdist | lacpdef | lacpexpire}] [padminsyspri padminsyspri] [padminsysid
padminsysid] [padminkey padminkey] [padminportpri padminportpri] [padminport
padminport] [padminstate {lacpactive | lacptimeout | lacpagg | lacpsync |
lacpcollect | lacpdist | lacpdef | lacpexpire}] [enable | [disable]}
Parameters
portport‐string Specifiesthephysicalport(s)onwhichtoconfigureLACP.Fora
detaileddescriptionofpossibleport‐stringvalues,referto“PortString
SyntaxUsedintheCLI”onpage 4‐2.
aadminkeyaadminkey Setstheport’sactoradminkey.LACPwillusethisvaluetoforman
operkey
andwilldeterminewhichunderlyingphysicalportsare
capableofaggregatingbycomparingoperkeys.Aggregatorportsallow
onlyunderlyingportswithoperkeysmatchingtheirstojointheirLAG.
Validvaluesare1‐65535.
aportpriaportpri Setstheport’sactorportpriority.Validvaluesare0‐65535,withlower
valuesdesignatinghigherpriority.
asyspriasyspri Setstheport’sactorsystempriority.TheLACPimplementationonthe
MatrixSeriesdeviceusesthisvaluetodetermineaggregation
precedencewhentherearetwodevicescompetingforthesame
aggregator.Validvaluesare0‐65535,withhigherprecedencegivento
lowervalues.
Note: Only one LACP system priority can be set on a Matrix Series device,
using either this command, or the set lacp asyspri command (“set lacp asyspri”
on page 4-60).
